SKF split plummer block housing bearing SNL series catalogue
| dia | H | L | Weightt | NO. | ||||
| d1(mm) | (kg) | NO. | QTY | |||||
| SNL507-606 | 30 | 93 | 185 | 2.4 | TSNG507 | 1207K | FR72x5.5 | 2 |
| TSNS507 | ||||||||
| SNL508-607 | 35 | 108 | 205 | 3.2 | TSNG508 | 1208K | FR80x8 | 2 |
| TSNS508 | ||||||||
| SNL509 | 40 | 109 | 205 | 3.5 | TSNG509 | 1209K | FR85x3.5 | 2 |
| TSNS509 | ||||||||
| SNL510-608 | 45 | 113 | 205 | 3.85 | TSNG510 | 1210K | FR90x9 | 2 |
| TSNS510 | ||||||||
| SNL511-609 | 50 | 128 | 255 | 5.4 | TSNG511 | 1211K | FR100x9.5 | 2 |
| TSNS511 | ||||||||
| SNL512-610 | 55 | 134 | 255 | 6.7 | TSNG512 | 1212K | FR110x10 | 2 |
| TSNS512 | ||||||||
| SNL513-611 | 60 | 149 | 275 | 7.9 | TSNG513 | 1213K | FR120x10 | 2 |
| TSNS513 | ||||||||
| SNL515-612 | 65 | 155 | 280 | 9.7 | TSNG515 | 1215K | FR130x12.5 | 2 |
| TSNS515 | ||||||||
| SNL516-613 | 70 | 177 | 315 | 11.5 | TSNG516 | 1216K | FR140x12.5 | 2 |
| TSNS516 | ||||||||
| SNL517 | 75 | 183 | 320 | 12.8 | TSNG517 | 1217K | FR150x12.5 | 2 |
| TSNS517 | ||||||||
| SNL518-615 | 80 | 194 | 345 | 15.4 | TSNG518 | 1218K | FR160x12.5 | 2 |
| TSNS518 | 22218K | FR160x6.25 | 2 | |||||
| SNL519-616 | 85 | 212 | 345 | 16.4 | TSNG519 | 1219K | FR170x12.5 | 2 |
| TSNS519 | ||||||||
| SNL520-617 | 90 | 218 | 380 | 20.4 | TSNG520 | 1220K | FR180x12 | 2 |
| TSNS520 | 22220K | FR180x4.85 | 2 | |||||
| SNL522-619 | 100 | 242 | 410 | 26.5 | TSNG522 | 1222K | FR200x13.5 | 2 |
| TSNS522 | 22222K | FR200x5.1 | 2 | |||||
| SNL524-620 | 110 | 271 | 410 | 32.2 | TSNG524 | 1224K | FR215x5 | 2 |
| TSNS524 | 22224K | 2 | ||||||
| SNL526 | 115 | 290 | 445 | 39.8 | TSNG526 | 22226K | FR230x5 | 2 |
| TSNS526 | ||||||||
| SNL528 | 125 | 302 | 500 | 48.8 | TSNG528 | 22228K | FR250x5 | 2 |
| TSNS528 |
