进口SKF英制调心球轴承RL14内径44.45mm外径95.25mm厚度20.638mm

进口SKF英制调心球轴承RL14内径44.45mm外径95.25mm厚度20.638mm

  • 型号：
  • RL14
  • 品牌：
  • SKF轴承
  • 系列：
  • 内径d：
  • 44.45mm mm
  • 外径D：
  • 95.25mm mm
  • 厚度B：
  • 20.638mm mm
进口SKF英制调心球轴承RL14内径44.45mm外径95.25mm厚度20.638mm参数

参数信息

品牌
SKF/斯凯孚
型号
RL14
颜色分类
银色
是否标准件
否
滚动体列数
双列
是否进口
是
滚动轴承座材质：
轴承钢
内径（mm）
其他

图文详情

品牌 SKF 型号 英制调心球轴承RL14 加工定制 是
是否标准件 标准件 样品或现货 现货 是否进口 进口
类型 钢球 用途 调心球轴承 材质 碳钢
尺寸 英制调心球轴承RL14



SKF英制调心球轴承RL14内径44.45mm外径95.25mm厚度20.638mm


SKF英制调心球轴承RL14内径44.45mm外径95.25mm厚度20.638mm

  SKF轴承RL14

SKF轴承RL14 (2)

SKF轴承RL14 (3)

STEYRFAGRHPSKF
NL 4 RLS 5 LRJ 1/2 CRL 4
NL 5 RLS 7 LRJ 5/8 CRL 5
NL 6 RLS 8 LRJ 3/4 CRL 6
NL 7 RLS 9 LRJ 7/8 CRL 7
NL 8 RLS 10 LRJ 1 E CRL 8
NL 9 RLS 11 LRJ 1 1/8 CRL 9



NL 10 RLS 12 LRJ 1 1/4 CRL 10
NL 11 RLS 12 1/2 LRJ 1 3/8 CRL 11
NL 12 RLS 13 LRJ 1 1/2 CRL 12
NL 13 RLS 13 1/2 LRJ 1 5/8 CRL 13
NL 14 RLS 14 LRJ 1 3/4 CRL 14
NL 15 RLS 14 1/2 LRJ 1 7/8 CRL 15



NL 16 RLS 15 LRJ 2 E CRL 16
NL 18 RLS 16 LRJ 2 1/4 CRL 18
NL 20 RLS 17 LRJ 2 1/2 CRL 20
NL 22 RLS 18 LRJ 2 3/4 CRL 22
NL 24 RLS 19 LRJ 3 E CRL 24
NL 26 RLS 19 1/2 LRJ 3 1/4 CRL 26



NL 28 RLS 20 LRJ 3 1/2 CRL 28
NL 30 RLS 20 1/2 LRJ 3 3/4 CRL 30
NL 32 RLS 21 LRJ 4 E CRL 32
NL 34 RLS 21 1/2 LRJ 4 1/4 CRL 34
NL 36 RLS 22 LRJ 4 1/2 CRL 36
NL 38 RLS 22 1/2 LRJ 4 3/4 CRL 38



NL 40 RLS 23 LRJ 5 E CRL 40
NL 44 RLS 23 1/2 LRJ 5 1/2 CRL 44
NL 48 RLS 24 LRJ 6 E CRL 48



PART B - MEDIUM SERIES CYLINDRICAL ROLLER BEARINGS ( INCH SERIES )
(OUTER RING SLIDES BOTH WAYS)



STEYRFAGRHPSKF
NM 4 RMS 5 MRJ 1/2 CRM 4
NM 5 RMS 7 MRJ 5/8 CRM 5
NM 6 RMS 8 MRJ 3/4 CRM 6
NM 7 RMS 9 MRJ 7/8 CRM 7
NM 8 RMS 10 MRJ 1 E CRM 8
NM 9 RMS 11 MRJ 1 1/8 CRM 9




NM 10 RMS 12 MRJ 1 1/4 CRM 10
NM 11 RMS 12 1/2 MRJ 1 3/8 CRM 11
NM 12 RMS 13 MRJ 1 1/2 CRM 12
NM 13 RMS 13 1/2 MRJ 1 5/8 CRM 13
NM 14 RMS 14 MRJ 1 3/4 CRM 14
NM 15 RMS 14 1/2 MRJ 1 7/8 CRM 15




NM 16 RMS 15 MRJ 2 E CRM 16
NM 18 RMS 16 MRJ 2 1/4 CRM 18
NM 20 RMS 17 MRJ 2 1/2 CRM 20
NM 22 RMS 18 MRJ 2 3/4 CRM 22
NM 24 RMS 19 MRJ 3 E CRM 24
NM 26 RMS 19 1/2 MRJ 3 1/4 CRM 26



NM 28 RMS 20 MRJ 3 1/2 CRM 28
NM 30 RMS 20 1/2 MRJ 3 3/4 CRM 30
NM 32 RMS 21 MRJ 4 E CRM 32
NM 34 RMS 21 1/2 MRJ 4 1/4 CRM 34
NM 36 RMS 22 MRJ 4 1/2 CRM 36
NM 38 RMS 22 1/2 MRJ 4 3/4 CRM 38



NM 40 RMS 23 MRJ 5 E CRM 40
NM 44 RMS 23 1/2 MRJ 5 1/2 CRM 44
NM 48 RMS 24 MRJ 6 E CRM 48



PART C - LIGHT SERIES CYLINDRICAL ROLLER BEARINGS ( INCH SERIES )
(OUTER RINGS SLIDES ONLY ONE WAY)



STEYRFAGRHPSKF
NFL 4 RL 5 L LRJA 1/2 CFL 4
NFL 5 RL 7 L LRJA 5/8 CFL 5
NFL 6 RL 8 L LRJA 3/4 CFL 6
NFL 7 RL 9 L LRJA 7/8 CFL 7
NFL 8 RL 10 L LRJA 1 E CFL 8
NFL 9 RL 11 L LRJA 1 1/8 CFL 9




NFL 10 RL 12 L LRJA 1 1/4 CFL 10
NFL 11 RL 12 1/2 L LRJA 1 3/8 CFL 11
NFL 12 RL 13 L LRJA 1 1/2 CFL 12
NFL 13 RL 13 1/2 L LRJA 1 5/8 CFL 13
NFL 14 RL 14 L LRJA 1 3/4 CFL 14
NFL 15 RL 14 1/2 L LRJA 1 7/8 CFL 15



NFL 16 RL 15 L LRJA 2 E CFL 16
NFL 18 RL 16 L LRJA 2 1/4 CFL 18
NFL 20 RL 17 L LRJA 2 1/2 CFL 20
NFL 22 RL 18 L LRJA 2 3/4 CFL 22
NFL 24 RL 19 L LRJA 3 E CFL 24
NFL 26 RL 19 1/2 L LRJA 3 1/4 CFL 26



NFL 28 RL 20 L LRJA 3 1/2 CFL 28
NFL 30 RL 20 1/2L LRJA 3 3/4 CFL 30
NFL 32 RL 21 L LRJA 4 E CFL 32
NFL 34 RL 21 1/2L LRJA 4 1/4 CFL 34
NFL 36 RL 22 L LRJA 4 1/2 CFL 36
NFL 38 RL 22 1/2 L LRJA 4 3/4 CFL 38



NFL 40 RL 23 L LRJA 5 E CFL 40
NFL 44 RL 23 1/2L LRJA 5 1/2 CFL 44
NFL 48 RL 24 L LRJA 6 E CFL 48



PART D - MEDIUM SERIES CYLINDRICAL ROLLER BEARINGS ( INCH SERIES )
(OUTER RINGS SLIDES ONLY ONE WAY)



STEYRFAGRHPSKF
NFM 4 RM 5 L MRJA 1/2 CFM 4
NFM 5 RM 7 L MRJA 5/8 CFM 5
NFM 6 RM 8 L MRJA 3/4 CFM 6
NFM 7 RM 9 L MRJA 7/8 CFM 7
NFM 8 RM 10 L MRJA 1 E CFM 8
NFM 9 RM 11 L MRJA 1 1/8 CFM 9




NFM 10 RM 12 L MRJA 1 1/4 CFM 10
NFM 11 RM 12 1/2 L MRJA 1 3/8 CFM 11
NFM 12 RM 13 L MRJA 1 1/2 CFM 12
NFM 13 RM 13 1/2 L MRJA 1 5/8 CFM 13
NFM 14 RM 14 L MRJA 1 3/4 CFM 14
NFM 15 RM 14 1/2 L MRJA 1 7/8 CFM 15



NFM 16 RM15 L MRJA 2 E CFM 16
NFM 18 RM 16 L MRJA 2 1/4 CFM 18
NFM 20 RM 17 L MRJA 2 1/2 CFM 20
NFM 22 RM 18 L MRJA 2 3/4 CFM 22
NFM 24 RM 19 L MRJA 3 E CFM 24
NFM 26 RM 19 1/2 L MRJA 3 1/4 CFM 26



NFM 28 RM 20 L MRJA 3 1/2 CFM 28
NFM 30 RM 20 1/2L MRJA 3 3/4 CFM 30
NFM 32 RM 21 L MRJA 4 E CFM 32
NFM 34 RM 21 1/2L MRJA 4 1/4 CFM 34
NFM 36 RM 22 L MRJA 4 1/2 CFM 36
NFM 38 RM 22 1/2 L MRJA 4 3/4 CFM 38



NFM 40 RM 23 L MRJA 5 E CFM 40
NFM 44 RM 23 1/2L MRJA 5 1/2 CFM 44
NFM 48 RM 24 L MRJA 6 E CFM 48

SKFRL14轴承我司目前有部分库存，您可致电我司咨询销售人员关于轴承RL14的图纸、轴承RL14价格或同型号其他品牌替换等资料！我司与SKF厂家常年批量订购RL14，以保证RL14轴承质量正宗，价格最优。订购原装SKF RL14轴承请拨打：0532-83735255、13061287818
热销轴承型号：上一篇：SKF英制调心球轴承RL5TN9内径15.875mm外径39.687mm厚度11.113mm SKF 23132-2CS轴承 FAG推力角接触球轴承 7603040-TV NSK 40BNR10XTDUELP4高转速 精密 NSK 6014N轴承 TIMKEN HM807046/HM807010-B轴承 KOYO R18/17轴承 SKF 22212CC/W33轴承 NACHI深沟球轴承51101G NSK HR32320J轴承 下一篇：进口SKF英制深沟球轴承RMS16内径50.8mm外径114.3mm厚度26.988mm
进口SKF英制调心球轴承RL14内径44.45mm外径95.25mm厚度20.638mm轴承图纸
