进口NTN圆锥滚子轴承4T-32014X内径70mm外径110mm厚度25mm

进口NTN圆锥滚子轴承4T-32014X内径70mm外径110mm厚度25mm

  • 型号：
  • 4T-32014X
  • 品牌：
  • NTN轴承
  • 系列：
  • 内径d：
  • 70mm mm
  • 外径D：
  • 110mm mm
  • 厚度B：
  • 25mm mm
进口NTN圆锥滚子轴承4T-32014X内径70mm外径110mm厚度25mm参数

参数信息

品牌
NTN/恩梯恩
型号
4T-32014X
厚度（mm）
25mm
颜色分类
银色
是否标准件
是
滚动体列数
单列
是否进口
是
滚动轴承座材质：
轴承钢
内径（mm）
其他



图文详情



品牌 NTN 型号 圆锥滚子轴承4T-32014X 加工定制 是
是否标准件 标准件 样品或现货 现货 是否进口 进口
类型 钢球 用途 圆锥滚子轴承 材质 碳钢
尺寸 圆锥滚子轴承4T-32014X




进口NTN圆锥滚子轴承4T-32014X


根据 DIN ISO 355 / DIN 720 标准的主要尺寸，可分离，调节或成对

 NTN轴承4T-32014X

NTN轴承4T-32014X (2)

NTN轴承4T-32014X (3)


圆锥滚子轴承 32014-X, 根据 DIN ISO 355 / DIN 720 标准的主要尺寸，可分离，调节或成对
径向载荷单向轴向载荷无密封脂润滑油润滑
圆锥滚子轴承 32014-X, 根据 DIN ISO 355 / DIN 720 标准的主要尺寸，可分离，调节或成对


d 70 mm

D 110 mm

T 25 mm


a 24 mm

B 25 mm

C 19 mm

Ca min 5 mm

Cb min 6 mm

Da max 103 mm

Da min 98 mm

Db min 105 mm

d1 92 mm

da max 78 mm

db min 77 mm

r1, 2 min 1,5 mm

r3, 4 min 1,5 mm

ra max 1,5 mm

rb max 1,5 mm


m 0,967 kg
  质量
Cr 104000 N
  基本额定动载荷，径向
C0r 159000 N
  基本额定静载荷，径向
e 0,43

Y 1,38

Y0 0,76

Cur 20100 N
  疲劳极限载荷，径向
nG 6300 1/min
  极限转速
nB 3800 1/min
  参考速度
  T4CC070
  根据 DIN ISO 355 的对应型号



類別 種類 NTN型號 說明
C A 4T-320/22X SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-320/22XCSTPX1 SMALL SIZE TAPERED ROLLER BEARINGS
J B 4T-320/22XP5 PRECISION TAPERED ROLLER BEARINGS
C A 4T-320/22XX2 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-320/28X SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-320/28X#G SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-320/28XDB+5CS50 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-320/28XSTPX2V6 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-320/28XT2LX2 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-320/28XU71 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-320/28XU87 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-320/28XV8-G SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-320/28XX1 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-320/28XX3PX1 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-320/32X SMALL SIZE TAPERED ROLLER BEARINGS
J B 4T-320/32XP5 PRECISION TAPERED ROLLER BEARINGS
C A 4T-320/32XU60 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-320/32XV5 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-320/32XW3-1 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-320/32XX1 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32004X SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32004XDB+3.5 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32004XDB+3.5DX SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32004XDB+5CS40 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32004XDFD0CS120 SMALL SIZE TAPERED ROLLER BEARINGS
J B 4T-32004XP5 PRECISION TAPERED ROLLER BEARINGS
C A 4T-32004XP6 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32004XPX2V1 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32004XU2 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32005X SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32005X#G SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32005X#GU61 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32005XDF-AP5 SMALL SIZE TAPERED ROLLER BEARINGS
J B 4T-32005XP5 PRECISION TAPERED ROLLER BEARINGS
C A 4T-32005XP6 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32005XP6X SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32005XPX4 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32005XSTDB+3.5DX SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32005XSTU35K SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32005XT2 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32005XT2-G SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32005XT2L SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32005XU60 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32005XU68 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32005XX3PX1 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32006X SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32006XDB+4.58#02 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32006XDB+4C2 SMALL SIZE TAPERED ROLLER BEARINGS
J B 4T-32006XP5 PRECISION TAPERED ROLLER BEARINGS
C A 4T-32006XP6 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32006XPX2 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32006XSTPX1 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32006XT2 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32006XT2LX3 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32006XU35K SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32006XV1 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32007X SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32007XDB+4DXPX4 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32007XDB+6CS60 SMALL SIZE TAPERED ROLLER BEARINGS
J B 4T-32007XP5 PRECISION TAPERED ROLLER BEARINGS
C A 4T-32007XP6 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32007XPX2 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32007XU35K SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32007XX2 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008X SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008X#G SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008X#GU70 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008X-GU70 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008X/38PX14 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008XDB+10/G#02 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008XDB+10D1#03 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008XDB+12 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008XDB+6 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008XDB+6DCS#01 SMALL SIZE TAPERED ROLLER BEARINGS
J B 4T-32008XDB+8/G10P5 PRECISION TAPERED ROLLER BEARINGS
J B 4T-32008XP5 PRECISION TAPERED ROLLER BEARINGS
C A 4T-32008XP6X#G#CA SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008XP6X-G#CA SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008XPX14 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008XST SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008XST#G SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008XST-G SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008XSTX5PX4 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008XU35K SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008XU42 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008XU64 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008XU70 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32008XU71 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32009X SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32009XDB+0/10#04 SMALL SIZE TAPERED ROLLER BEARINGS
J B 4T-32009XDB+50DX#01 PRECISION TAPERED ROLLER BEARINGS
C A 4T-32009XDB+6DX2#04 SMALL SIZE TAPERED ROLLER BEARINGS
J B 4T-32009XP5 PRECISION TAPERED ROLLER BEARINGS
C A 4T-32009XP6X#CA SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32009XPX4 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32009XST#G SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32009XST-G SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32009XSTPX5 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32009XU2 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32009XU35K SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32009XU42 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32009XU54 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32009XU74 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32009XU75 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32009XU91 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32009XX2DB+4.#06 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32010X SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32010X#G SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32010X-G SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32010XDB+0/5.#04 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32010XDB+0/5.#06 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32010XDB+0/5.#07 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32010XDB+6DX3#04 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32010XP6X#G#CA SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32010XP6X-G#CA SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32010XSTPX3 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32010XSTX7PX3 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32010XSTXPX3 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32010XU35K SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32010XU42 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32011X SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32011X#GU51 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32011X-GU51 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32011XDB+0/6D#02 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32011XDF-AP5 SMALL SIZE TAPERED ROLLER BEARINGS
J B 4T-32011XP5 PRECISION TAPERED ROLLER BEARINGS
C A 4T-32011XPX1 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32011XST SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32011XSTPX4 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32011XSTU35K SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32011XU2 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32011XU36 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32011XU42 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32011XU50 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32011XU72 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32011XU74 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32011XU75 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32012X SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32012X#G SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32012X-G SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32013XE4 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32013XPX1 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32013XST SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32013XX1 SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32013XX2-G SMALL SIZE TAPERED ROLLER BEARINGS
C A 4T-32013XX3-G SMALL SIZE TAPERED ROLLER BEARINGS
C B 4T-32014X MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32014X#G MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32014X-G MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32014XDB+0/37#02 MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32014XDB+0/37#04 MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32014XDB+7DX1#01 MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32014XU36 MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32015X MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32015XPX1 MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32015XPX1U35K MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32015XST MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32015XSTDFCS1#01 MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32015XSTDFCS1#02 MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32015XSTU35K MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32015XU35K MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32015XX3PX1 MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32016X MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32016X/4T-322#01 MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32016X/4T-322#02 MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32016XSTPX5-G MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32016XSTPX6 MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32018X MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32018X/4T-322#03 MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32018X/4T-322#05 MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32020X MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32020X#G MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32020X-G MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32020X-GU35K MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32020XP6 MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32020XPX4#G MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32020XPX4#GU35K MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32020XPX4U35K MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32020XU35K MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32021X MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32021X#G MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32021X-G MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32021XU35K MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32024X MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32024XDFC3 MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32024XDFC3U35K MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32024XE1 MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32024XPX4V2 MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32024XPX4V2U35K MEDIUM SIZE TAPERED ROLLER BEARINGS
C B 4T-32024XU35K MEDIUM SIZE TAPERED ROLLER BEARINGS
H C 4T-32028X TRB, LARGE SIZE
H C 4T-32028XU35K TRB, LARGE SIZE
H C 4T-32030X TRB, LARGE SIZE
H C 4T-32030XDB+40DX#01 TRB, LARGE SIZE
H C 4T-32030XPX4 TRB, LARGE SIZE
H C 4T-32030XPX4U35K TRB, LARGE SIZE
H C 4T-32030XU35K TRB, LARGE SIZE



NTN4T-32014X轴承我司目前有部分库存，您可致电我司咨询销售人员关于轴承4T-32014X的图纸、轴承4T-32014X价格或同型号其他品牌替换等资料！我司与NTN厂家常年批量订购4T-32014X，以保证4T-32014X轴承质量正宗，价格最优。订购原装NTN 4T-32014X轴承请拨打：0532-83735255、13061287818
热销轴承型号：上一篇：台湾ABBA直线运动滑块BRC25A0NZ0 TIMKEN 68462/68712-B轴承 TIMKEN 24FSH47轴承 NSK 1211轴承 SAMICK直线轴承支架SK-20 IKO CH30VB轴承 NTN AXK1124轴承 KOYO NUP1040轴承 KOYO 7215BDF轴承 IKO KT808822轴承 下一篇：SKF 深沟球轴承 6203-2RSH 两侧胶封 17mm X 40mm X 1 2mm
进口NTN圆锥滚子轴承4T-32014X内径70mm外径110mm厚度25mm轴承图纸

热门型号

更多>>
公司简介|经销品牌|技术新闻|轴承型号|售后服务|联系方式|
