NTN轴承7E-HMK5030
- 型号：
- 7E-HMK5030
- 品牌：
- NTN轴承
- 系列：
- 滚针轴承
- 内径d：
- 50 mm
- 外径D：
- 62 mm
- 厚度B：
- 30 mm
NTN轴承7E-HMK5030参数
NTN滚针轴承7E-HMK5030内径50mm外径62mm厚度30mm青岛瑞精机电现货供应0532-83735255
NTN滚针轴承7E-HMK5030内径50mm外径62mm厚度30mm轴承尺寸|轴承规格参数|轴承报价
内径：50mm
外径：62mm
宽度：30mm
型号：NTN滚针轴承7E-HMK5030内径50mm外径62mm厚度30mm
类型：滚针轴承
品牌：NTN
备注：滚针轴承
| Part Number | Dimension(mm) | ||
| Fw | D | C | |
| HMK0810 | 8 | 15 | 10 |
| HMK0815 | 8 | 15 | 15 |
| HMK0820 | 8 | 15 | 20 |
| HMK0912 | 9 | 16 | 12 |
| HMK0916 | 9 | 16 | 16 |
| HMK1010 | 10 | 17 | 10 |
| HMK1012 | 10 | 17 | 12 |
| HMK1015 | 10 | 17 | 15 |
| HMK1020 | 10 | 17 | 20 |
| HMK1212 | 12 | 19 | 12 |
| HMK1215 | 12 | 19 | 15 |
| HMK1220 | 12 | 19 | 20 |
| HMK1225 | 12 | 19 | 25 |
| HMK1416 | 14 | 22 | 16 |
| HMK1420 | 14 | 22 | 20 |
| HMK1510 | 15 | 22 | 10 |
| HMK1512 | 15 | 22 | 12 |
| HMK1515 | 15 | 22 | 15 |
| HMK1520 | 15 | 22 | 20 |
| HMK1525 | 15 | 22 | 25 |
| HMK1616 | 16 | 24 | 16 |
| HMK1620 | 16 | 24 | 20 |
| HMK1715 | 17 | 24 | 15 |
| HMK1720 | 17 | 24 | 20 |
| HMK1725 | 17 | 24 | 25 |
| HMK1813 | 18 | 25 | 13 |
| HMK1815 | 18 | 25 | 15 |
| HMK1817 | 18 | 25 | 17 |
| HMK1819 | 18 | 25 | 19 |
| HMK1820 | 18 | 25 | 20 |
| HMK1825 | 18 | 25 | 25 |
| HMK1916 | 19 | 27 | 16 |
| HMK1920 | 19 | 27 | 20 |
| HMK2015 | 20 | 27 | 15 |
| HMK2020 | 20 | 27 | 20 |
| HMK2025 | 20 | 27 | 25 |
| HMK2030 | 20 | 27 | 30 |
| HMK2116 | 21 | 29 | 16 |
| HMK2120 | 21 | 29 | 20 |
| HMK2210 | 22 | 29 | 10 |
| HMK2215 | 22 | 29 | 15 |
| HMK2220 | 22 | 29 | 20 |
| HMK2225 | 22 | 29 | 25 |
| HMK2230 | 22 | 29 | 30 |
| HMK2420 | 24 | 31 | 20 |
| HMK2428 | 24 | 31 | 28 |
| HMK2510 | 25 | 33 | 10 |
| HMK2515 | 25 | 33 | 15 |
| HMK2520 | 25 | 33 | 20 |
| HMK2525 | 25 | 33 | 25 |
| HMK2530 | 25 | 33 | 30 |
| HMK2616 | 26 | 34 | 16 |
| HMK2620 | 26 | 34 | 20 |
| HMK2820 | 28 | 37 | 20 |
| HMK2830 | 28 | 37 | 30 |
| HMK2920 | 29 | 38 | 20 |
| HMK2930 | 29 | 38 | 30 |
| HMK3013 | 30 | 40 | 13 |
| HMK3015 | 30 | 40 | 15 |
| HMK3020 | 30 | 40 | 20 |
| HMK3025 | 30 | 40 | 25 |
| HMK3030 | 30 | 40 | 30 |
| HMK3220 | 32 | 42 | 20 |
| HMK3230 | 32 | 42 | 30 |
| HMK3512 | 35 | 45 | 12 |
| HMK3515 | 35 | 45 | 15 |
| HMK3520 | 35 | 45 | 20 |
| HMK3525 | 35 | 45 | 25 |
| HMK3530 | 35 | 45 | 30 |
| HMK3720 | 37 | 47 | 20 |
| HMK3730 | 37 | 47 | 30 |
| HMK3815 | 38 | 48 | 15 |
| HMK3820 | 38 | 48 | 20 |
| HMK3825 | 38 | 48 | 25 |
| HMK3830 | 38 | 48 | 30 |
| HMK3845 | 38 | 48 | 45 |
| HMK4015 | 40 | 50 | 15 |
| HMK4020 | 40 | 50 | 20 |
| HMK4025 | 40 | 50 | 25 |
| HMK4030 | 40 | 50 | 30 |
| HMK4040 | 40 | 50 | 40 |
| HMK4520 | 45 | 55 | 20 |
| HMK4525 | 45 | 55 | 25 |
| HMK4530 | 45 | 55 | 30 |
| HMK4540 | 45 | 55 | 40 |
| HMK5012 | 50 | 62 | 12 |
| HMK5015 | 50 | 62 | 15 |
| HMK5020 | 50 | 62 | 20 |
| HMK5025 | 50 | 62 | 25 |
| HMK5030 | 50 | 62 | 30 |
| HMK5040 | 50 | 62 | 40 |
| HMK5045 | 50 | 62 | 45 |
NTN滚针轴承7E-HMK5030轴承我司目前有部分库存，您可致电我司咨询销售人员关于轴承7E-HMK5030的图纸、轴承7E-HMK5030价格或同型号其他品牌替换等资料！我司与NTN厂家常年批量订购7E-HMK5030滚针轴承，以保证7E-HMK5030轴承质量正宗，价格最优。订购原装NTN 7E-HMK5030轴承请拨打：0532-83735255、13061287818
