精密NSK轴承220BT19XDBLP4A精密背对背组合进口角接触球轴承

精密NSK轴承220BT19XDBLP4A精密背对背组合进口角接触球轴承

  • 型号：
  • 220BT19XDBLP4A
  • 品牌：
  • NSK轴承
  • 系列：
  • 内径d：
  • mm
  • 外径D：
  • mm
  • 厚度B：
  • mm
精密NSK轴承220BT19XDBLP4A精密背对背组合进口角接触球轴承参数

参数信息

品牌
NSK/恩斯凯
厚度（mm）
38mm
颜色分类
浅灰色
是否标准件
是
滚动体列数
双列
是否进口
是
滚动轴承座材质：
轴承钢
内径（mm）
其他

图文详情

品牌 NSK 型号 主轴轴承 220BT19XDBLP4A 加工定制 是
是否标准件 标准件 样品或现货 现货 是否进口 进口
类型 钢球 用途 滑动轴承 材质 碳钢
尺寸 主轴轴承220BT19XDBLP4A


主轴轴承精密NSK轴承220BT19XDBLP4A


调节，成对或单元安装，接触角 α = 40°，限制公差

  IMG_8767

IMG_8768

IMG_8767



主轴轴承 B71944-E-T-P4S, 调节，成对或单元安装，接触角 α = 25°，限制公差
径向载荷单向轴向载荷无密封脂润滑油润滑
主轴轴承 B71944-E-T-P4S, 调节，成对或单元安装，接触角 α = 25°，限制公差
主轴轴承 B71944-E-T-P4S, 调节，成对或单元安装，接触角 α = 25°，限制公差


d 220 mm

D 300 mm

B 38 mm


a 80 mm

Da H12 286 mm

da h12 234 mm

r1 min 1,1 mm

ra max 1 mm

ra1 max 1 mm

rmin 2,1 mm


m 6,58 kg
  质量
Cr 212000 N
  基本额定动载荷，径向
C0r 192000 N
  基本额定静载荷，径向
f0 16,5

nG Fett 3800 1/min
  脂润滑时的极限转速
nG Öl 6000 1/min
  最少油润滑时的极限转速
Cur 12200 N
  疲劳极限载荷，径向

  NSK170TAC20XPN7+LC62NSK170TAC29DPN7+LC72NSK170TMP9310NSK17TAC47BDDGSUC10PN0110NSK17TAC47BSUC10PN7B1NSK17TAC47BSUC10PN7B8NSK17TAC47BSUC10PN7B17NSK17TAC47BSUC10PN7B20NSK17TAC47BSUC10PN7B114NSK17TAC47BSUC10PN7B60NSK17TAC47BSUC10PN7B60NSK17TAC47BSUC10PN7B100NSK17TAC47BSUC10PN7B100NSK17TAC47BSUC10PN7B100NSK17TAC47BSUC10PN7B100NSK17TAC47BSUC10PN7B200NSK180TAC20XPN7+LC71NSK180TAC29DPN7+LC72NSK180TMP12P44NSK180TMP12P44NSK190TAC29DPN7+LC74NSK200TAC20DPN7+LC73NSK200TAC29DEPN7+LC72NSK200TMP11P54NSK200TMP11P510NSK200TMP12P51NSK200TMP12P54NSK200TMP12P51NSK200TMP12P52NSK20BGR19XTDTP410NSK20BGR19XTDTP410NSK20TAC47BDDGSUC10PN011NSK20TAC47BDFC10PN7A1NSK20TAC47BSUC10PN7B19NSK20TAC47BSUC10PN7B300NSK20TAC47BSUC10PN7B10NSK20TAC47BSUC10PN7B730NSK20TAC47BSUC10PN7B60NSK20TAC47BSUC10PN7B579NSK20TAC47BSUC10PN7B1000NSK21305CDE4100NSK21306CDE4S11135NSK21306CDE4S1143NSK21306CDE4S11146NSK21307CDE48NSK21307CDE499NSK21308EAKE410NSK21308EAKE4C310NSK21309EAE433NSK21309EAKE42NSK21310EAE42NSK21310EAE44NSK21310EAE410NSK21310EAKE410NSK21310EAKE4C310NSK21311EAE4125NSK21311EAE426NSK21312EAE47NSK21312EAE4C36NSK21312EAKE467NSK21312EAKE412NSK21313EAE469NSK21313EAE480NSK21313EAE4C335NSK21314EAE41NSK21314EAE43NSK21314EAKE4C35NSK21315EAE410NSK21315EAE410NSK21315EAE42NSK21315EAE43NSK21315EAE43NSK21315EAE430NSK21315EAE420NSK21315EAE4C34NSK21315EAKE45NSK21316EAE41NSK21316EAE44NSK21316EAE430NSK21316EAE47NSK21316EAE45NSK21317EAE410NSK21317EAE410NSK21317EAE410NSK21317EAE45NSK21317EAE4C388NSK21317EAE4C33NSK21317EAE4C31NSK21317EAKE4C35NSK21318EAE41NSK21320CE42NSK21322CAME4S112NSK2200100NSK2200410NSK22011NSK22012900NSK22026NSK220240NSK2202500NSK22031000NSK2204200NSK2204195NSK2204-2RSTNG4NSK2204K10NSK2204K49NSK22053NSK220584NSK220550NSK2205100NSK2205K10NSK2205K10NSK2206195NSK2206100NSK2206K13NSK220720NSK220724NSK220814NSK2208C31NSK22096NSK220BT19XDBLP4A8NSK220TMP112NSK220TMP11P41NSK220TMP11P44NSK220TMP11P44NSK220TMP11P43NSK220TMP121NSK220TMP121NSK220TMP121NSK220TMP12P52NSK220TMP12P51NSK221120NSK22125NSK221220NSK22131NSK22136NSK22136NSK22142NSK221414NSK2215KC32NSK2216K1NSK22172NSK2217K2NSK22193NSK22205CE4C3S111NSK22205CE4S112NSK22207CE4S1165NSK22207CE4S11100NSK22207CE4S118NSK22208EAE498NSK22208EAE480NSK22208EAE4C31NSK22209EAE4100NSK22209EAE418NSK22209EAE4C347NSK22209EAKE4C33SKF22210E/C32NSK22210EAE411NSK22210EAE44NSK22210EAE450NSK22210EAKE470NSK22210EAKE48NSK22211EAE4572NSK22211EAE4C34NSK22211EAKE41NSK22211EAKE4C31NSK22212EAE419NSK22212EAE42NSK22212EAE4C31NSK22212EAE4C31NSK22212EAE4C340NSK22212EAKE445NSK22212EAKE4C31NSK22213EAE49NSK22213EAKE4C31NSK22214EAE4309NSK22214EAE4150NSK22214EAE430NSK22214EAE418NSK22214EAE410NSK22214EAE450NSK22214EAE4C313NSK22214EAKE45NSK22214EAKE48NSK22215EAE43NSK22215EAE450NSK22216EAE450NSK22216EAE4C329NSK22216EAE4C382NSK22217EAE498NSK22217EAE41NSK22217EAE4100NSK22217EAE4270NSK22218EAE449NSK22219EAE432NSK22219EAE440NSK22219EAE450NSK22219EAE4C35NSK22219EAE4C351NSK22219EAKE48NSK22219EAKE420NSK22219EAKE410NSK22225NSK22220EAE4168NSK22220EAE41NSK22220EAE41NSK22220EAE430NSK22220EAE4100NSK22220EAE4C311NSK22220EAE4U122NTN22222BKD1C350NSK22222CAME4C32NSK22222EAE425NSK22222EAE430SY-NSK22222EAKE46SY-NSK22222EAKE46SKF22224E/C31NSK22224EAE44

NSK170TAC20XPN7+LC62NSK170TAC29DPN7+LC72NSK170TMP9310NSK17TAC47BDDGSUC10PN0110NSK17TAC47BSUC10PN7B1NSK17TAC47BSUC10PN7B8NSK17TAC47BSUC10PN7B17NSK17TAC47BSUC10PN7B20NSK17TAC47BSUC10PN7B114NSK17TAC47BSUC10PN7B60NSK17TAC47BSUC10PN7B60NSK17TAC47BSUC10PN7B100NSK17TAC47BSUC10PN7B100NSK17TAC47BSUC10PN7B100NSK17TAC47BSUC10PN7B100NSK17TAC47BSUC10PN7B200NSK180TAC20XPN7+LC71NSK180TAC29DPN7+LC72NSK180TMP12P44NSK180TMP12P44NSK190TAC29DPN7+LC74NSK200TAC20DPN7+LC73NSK200TAC29DEPN7+LC72NSK200TMP11P54NSK200TMP11P510NSK200TMP12P51NSK200TMP12P54NSK200TMP12P51NSK200TMP12P52NSK20BGR19XTDTP410NSK20BGR19XTDTP410NSK20TAC47BDDGSUC10PN011NSK20TAC47BDFC10PN7A1NSK20TAC47BSUC10PN7B19NSK20TAC47BSUC10PN7B300NSK20TAC47BSUC10PN7B10NSK20TAC47BSUC10PN7B730NSK20TAC47BSUC10PN7B60NSK20TAC47BSUC10PN7B579NSK20TAC47BSUC10PN7B1000NSK21305CDE4100NSK21306CDE4S11135NSK21306CDE4S1143NSK21306CDE4S11146NSK21307CDE48NSK21307CDE499NSK21308EAKE410NSK21308EAKE4C310NSK21309EAE433NSK21309EAKE42NSK21310EAE42NSK21310EAE44NSK21310EAE410NSK21310EAKE410NSK21310EAKE4C310NSK21311EAE4125NSK21311EAE426NSK21312EAE47NSK21312EAE4C36NSK21312EAKE467NSK21312EAKE412NSK21313EAE469NSK21313EAE480NSK21313EAE4C335NSK21314EAE41NSK21314EAE43NSK21314EAKE4C35NSK21315EAE410NSK21315EAE410NSK21315EAE42NSK21315EAE43NSK21315EAE43NSK21315EAE430NSK21315EAE420NSK21315EAE4C34NSK21315EAKE45NSK21316EAE41NSK21316EAE44NSK21316EAE430NSK21316EAE47NSK21316EAE45NSK21317EAE410NSK21317EAE410NSK21317EAE410NSK21317EAE45NSK21317EAE4C388NSK21317EAE4C33NSK21317EAE4C31NSK21317EAKE4C35NSK21318EAE41NSK21320CE42NSK21322CAME4S112NSK2200100NSK2200410NSK22011NSK22012900NSK22026NSK220240NSK2202500NSK22031000NSK2204200NSK2204195NSK2204-2RSTNG4NSK2204K10NSK2204K49NSK22053NSK220584NSK220550NSK2205100NSK2205K10NSK2205K10NSK2206195NSK2206100NSK2206K13NSK220720NSK220724NSK220814NSK2208C31NSK22096NSK220BT19XDBLP4A8NSK220TMP112NSK220TMP11P41NSK220TMP11P44NSK220TMP11P44NSK220TMP11P43NSK220TMP121NSK220TMP121NSK220TMP121NSK220TMP12P52NSK220TMP12P51NSK221120NSK22125NSK221220NSK22131NSK22136NSK22136NSK22142NSK221414NSK2215KC32NSK2216K1NSK22172NSK2217K2NSK22193NSK22205CE4C3S111NSK22205CE4S112NSK22207CE4S1165NSK22207CE4S11100NSK22207CE4S118NSK22208EAE498NSK22208EAE480NSK22208EAE4C31NSK22209EAE4100NSK22209EAE418NSK22209EAE4C347NSK22209EAKE4C33SKF22210E/C32NSK22210EAE411NSK22210EAE44NSK22210EAE450NSK22210EAKE470NSK22210EAKE48NSK22211EAE4572NSK22211EAE4C34NSK22211EAKE41NSK22211EAKE4C31NSK22212EAE419NSK22212EAE42NSK22212EAE4C31NSK22212EAE4C31NSK22212EAE4C340NSK22212EAKE445NSK22212EAKE4C31NSK22213EAE49NSK22213EAKE4C31NSK22214EAE4309NSK22214EAE4150NSK22214EAE430NSK22214EAE418NSK22214EAE410NSK22214EAE450NSK22214EAE4C313NSK22214EAKE45NSK22214EAKE48NSK22215EAE43NSK22215EAE450NSK22216EAE450NSK22216EAE4C329NSK22216EAE4C382NSK22217EAE498NSK22217EAE41NSK22217EAE4100NSK22217EAE4270NSK22218EAE449NSK22219EAE432NSK22219EAE440NSK22219EAE450NSK22219EAE4C35NSK22219EAE4C351NSK22219EAKE48NSK22219EAKE420NSK22219EAKE410NSK22225NSK22220EAE4168NSK22220EAE41NSK22220EAE41NSK22220EAE430NSK22220EAE4100NSK22220EAE4C311NSK22220EAE4U122NTN22222BKD1C350NSK22222CAME4C32NSK22222EAE425NSK22222EAE430SY-NSK22222EAKE46SY-NSK22222EAKE46SKF22224E/C31NSK22224EAE44


NSK220BT19XDBLP4A轴承我司目前有部分库存，您可致电我司咨询销售人员关于轴承220BT19XDBLP4A的图纸、轴承220BT19XDBLP4A价格或同型号其他品牌替换等资料！我司与NSK厂家常年批量订购220BT19XDBLP4A，以保证220BT19XDBLP4A轴承质量正宗，价格最优。订购原装NSK 220BT19XDBLP4A轴承请拨打：0532-83735255、13061287818
热销轴承型号：上一篇： 进口NSK轴承200TAC20DPN7+LC7高精度双向推力角接触球轴承 NSK 7922CTYNSULP4轴承 SKF NJ215EC轴承 TIMKEN G1014KRRB轴承 NTN WS81115轴承 KOYO NJ2313R轴承 KOYO NF324轴承 TIMKEN GY1204KRRB轴承 SKF BK1616轴承 FAG AH3160G轴承 下一篇：德国Freudenberg科德宝油封T20 70X80X11.8进口密封件
精密NSK轴承220BT19XDBLP4A精密背对背组合进口角接触球轴承轴承图纸
