| 品牌 | MPB | 型号 | FT-09 | 旧型号 | FT09 |
| 内径 | 7.938（mm） | 外径 | 21.431（mm） | 厚度 | 9.525（mm） |
| 重量 | 1（kg） | 保持架及其材料 | N黄铜实体 | 滚动体列数 | 多列 |
| 滚道类型 | 直线滚道 | 使用特性 | 高温 | 轴承材料 | HP |
| 滚动体类型 | 球 | 密封盖 | 无密封 | 滚动体 | 钢球 |
| 密封防尘形式 | M | 样品或现货 | 现货 | 是否提供加工定制 | 是 |
| 工作原理 | 滚动 |
美国MPB轴承FT-09英制非标微型推力球轴承青岛瑞精机电现货
美国MPB轴承FT-09英制非标微型推力球轴承轴承尺寸|轴承规格参数|轴承报价
内径：7.938mm
外径：21.431mm
宽度：9.525mm
型号：美国MPB轴承FT-09英制非标微型推力球轴承
类型：推力球轴承
品牌：美国MPB轴承FT-09英制非标微型推力球轴承
备注： 推力球轴承
Page 287 THRUST BALL BEARINGS - INCH DIMENSIONS - FLAT RACEWAYS
Bearing NO. Dimensions (Inch) Approx.
Wgt. lbs Interchange
d D H Aetna Andrews NICE MPB
FT-01 .1875 .4375 .1875 .006 - FT-01 FR-4
FT-02 .1875 .5312 .1875 .011 - FT-02 -
FT-03 .1875 .6250 .2500 .019 - FT-03 FR-5
FT-04 .1875 .9375 .3750 .064 - FT-04 -
FT-05 .2500 .5625 .2187 .011 - FT-05 FR-9
FT-06 .2500 .8125 .3750 .045 - FT-06 -
FT-07 .2500 .8437 .3750 .050 - FT-07 FR-11
FT-08 .3125 .6250 .2500 .016 - FT-08 FR-13
FT-09 .3125 .8437 .3750 .045 - FT-09 FR-15
FT-010 .3750 .6875 .2812 .019 - FT-010 FR-17
FT-011 .3750 1.0312 .5000 .088 - FT-011 FR-19
FT-012 .3750 1.0937 .5000 .100 - FT-012 -
FT-013 .4375 .8125 .3125 .028 - FT-013 FR-21
FT-014 .4375 1.0937 .5000 .109 - FT-014 FR-22
FT-015 .5000 .8750 .2500 .024 - FT-015 -
FT-016 .5000 .8750 .3750 .038 - FT-016 FR-24
FT-1 .5000 1.2187 .5625 .132 B-1 FT-1 -
FT-2 .5625 1.2187 .5625 .121 B-2 FT-2 -
FT-3 .6250 1.3437 .5625 .151 B-3 FT-3 -
FT-4 .6875 1.3437 .5625 .144 B-4 FT-4 -
FT-5 .7500 1.4687 .5625 .169 B-5 FT-5 -
FT-6 .8125 1.4687 .5625 .154 B-6 FT-6 -
FT-7 .8750 1.8437 .6250 .303 B-7 FT-7 -
FT-8 .9375 1.8437 .6250 .293 B-8 FT-8 -
FT-9 1.0000 1.9687 .6250 .325 B-9 FT-9 -
FT-10 1.0625 1.9687 .6250 .315 B-10 FT-10 -
FT-11 1.1250 2.0937 .6250 .367 B-11 FT-11 -
FT-12 1.1875 2.0937 .6250 .356 B-12 FT-12 -
FT-13 1.2500 2.3437 .6250 .480 B-13 FT-13 -
FT-14 1.3125 2.3437 .6250 .473 B-14 FT-14 -
FT-15 1.3750 2.4687 .6250 .516 B-15 FT-15 -
FT-16 1.4375 2.4687 .6250 .510 B-16 FT-16 -
FT-17 1.5000 2.5937 .6250 .547 B-17 FT-17 -
FT-18 1.5625 2.5937 .6250 .535 B-18 FT-18 -
FT-19 1.6250 2.9687 .8125 .931 B-19 FT-19 -
FT-20 1.6875 2.9687 .8125 .910 B-20 FT-20 -
FT-21 1.7500 3.0937 .8125 1.000 B-21 FT-21 -
FT-22 1.8125 3.0937 .8125 .993 B-22 FT-22 -
FT-23 1.8750 3.2187 .8125 1.070 B-23 FT-23 -
FT-24 1.9375 3.2187 .8125 .970 B-24 FT-24 -
FT-25 2.0000 3.3437 .8125 1.172 B-25 FT-25 -
FT-26 2.0625 3.3437 .8125 1.062 B-26 FT-26 -
FT-27 2.1250 3.5937 .8125 1.230 B-27 FT-27 -
FT-28 2.1875 3.5937 .8125 1.200 B-28 FT-28 -
FT-29 2.2500 3.7187 .8125 .685 B-29 FT-29 -
FT-30 2.3125 3.7187 .8125 1.313 B-30 FT-30 -
FT-31 2.3750 3.8437 .8125 1.370 B-31 FT-31 -
FT-32 2.4375 3.8437 .8125 1.380 B-32 FT-32 -
FT-33 2.5000 3.9687 .8125 1.420 B-33 FT-33 -
FT-34 2.5625 3.9687 .8125 1.360 - FT-34 -
FT-35 2.6250 4.3437 1.0000 2.280 - FT-35 -
FT-36 2.6875 4.3437 1.0000 2.330 - FT-36 -
FT-37 2.7500 4.4687 1.0000 2.390 B-37 FT-37 -
FT-38 2.8125 4.4687 1.0000 2.270 - FT-38 -
FT-39 2.8750 4.5937 1.0000 2.440 - FT-39 -
FT-40 2.9375 4.5937 1.0000 2.280 B-40 FT-40 -
FT-41 3.0000 4.7187 1.0000 2.500 B-41 FT-41 -
FT-42 3.0625 4.7187 1.0000 2.420 - FT-42 -
FT-43 3.2500 4.9687 1.0000 2.600 B-43 FT-43 -
FT-44 3.5000 5.2187 1.0000 2.800 B-45 FT-44 -
