DDL的公制L系列径向屏蔽微型/仪器仪表球轴承
公制尺寸系列。1毫米/0.0400“内径26毫米/0.8750”外径尺寸范围。他们设计进行
在小信封尺寸，同时提供高性能的中度低操作力矩的径向和推力负荷。轴承
在各个的ABEC在Chrome或不锈钢类的几个价格点。几种风格与扩展内圈
法兰。
DDL-520 2.0 mm 5.0 mm 2.3 mm Flanged
Standard
DDL-625 2.5 mm 6.0 mm 2.6 mm Flanged
Standard
DDL-630 3 mm 6.0 mm 2.5 mm Flanged
Standard
DDL-730 3 mm 7.0 mm 3 mm Flanged
Standard
DDL-740 4 mm 7.0 mm 2.5 mm Flanged
Standard
DDL-840 4 mm 8 mm 3 mm Flanged
Standard
DDL-940 4 mm 9 mm 4 mm Flanged
Standard
DDL-1040 4 mm 10 mm 4 mm Flanged
Standard
DDL-850 5 mm 8 mm 2.5 mm Flanged
Standard
DDL-950 5 mm 9 mm 3 mm Flanged
Standard
DDL-1050 5 mm 10 mm 4 mm Flanged
Standard
DDL-1150 5 mm 11 mm 5 mm Flanged
Standard
DDL-1060 6 mm 10 mm 3 mm Flanged
Standard
DDL-1260 6 mm 12 mm 4 mm Flanged
Standard
DDL-1360 6 mm 13 mm 5 mm Flanged
Standard
DDL-1170 7 mm 11 mm 3 mm Flanged
Standard
DDL-1370 7 mm 13 mm 4 mm Flanged
Standard
DDL-1470 7 mm 14 mm 5 mm Flanged
Standard
DDL-1280 8 mm 12 mm 3.5 mm Flanged
Standard
DDL-1480 8 mm 14 mm 4 mm Flanged
Standard
DDL-1680 8 mm 16 mm 5 mm Flanged
DDR系列径向屏蔽微型/仪器仪表球轴承
公制风格与孔径由1.5mm到8mm不等。他们的目的是在低工作进行适度的径向和推力负荷
扭矩，同时在小信封尺寸提供高性能。轴承是在几个价格点提供各种ABEC类
铬或不锈钢。几种风格与扩展内圈和法兰。
DDR-515 1.5 mm 5.0 mm 2.6 mm Flanged
Standard
DDR-615 1.5 mm 6.0 mm 3 mm Flanged
Standard
DDR-620 2.0 mm 6.0 mm 3 mm Flanged
Standard
DDR-720 2.0 mm 7.0 mm 3.5 mm Flanged
Standard
DDR-725 2.5 mm 7.0 mm 3.5 mm Flanged
Standard
DDR-825 2.5 mm 8 mm 4 mm Flanged
Standard
DDR-830 3 mm 8 mm 4 mm Flanged
Standard
DDR-930 3 mm 9 mm 5 mm Flanged
Standard
DDR-1030 3 mm 10 mm 4 mm Flanged
Standard
DDR-1140 4 mm 11 mm 4 mm Flanged
Standard
DDR-1240 4 mm 12 mm 4 mm Flanged
Standard
DDR-1340 4 mm 13 mm 5 mm Flanged
Standard
DDR-1640 4 mm 16 mm 5 mm Flanged
Standard
DDR-1350 5 mm 13 mm 4 mm Flanged
Standard
DDR-1450 5 mm 14 mm 5 mm Flanged
Standard
DDR-1650 5 mm 16 mm 5 mm Flanged
Standard
DDR-1950 5 mm 19 mm 6 mm Flanged
Standard
DDR-1560 6 mm 15 mm 5 mm Flanged
Standard
DDR-1760 6 mm 17 mm 6 mm Flanged
Standard
DDR-1960 6 mm 19 mm 6 mm Flanged
Standard
DDR-1970 7 mm 19 mm 6 mm Flanged
Standard
DDRI系列径向屏蔽微型/仪器仪表球轴承
英寸式微型轴承开放或特氟隆密封。1毫米/0.0400“内径尺寸范围
26毫米/0.8750“外径。他们的目的是在低操作力矩进行适度的径向和推力负荷而
小信封尺寸范围内提供高性能。轴承是在几个价格点提供各种ABEC
类中的铬或不锈钢。几种风格与扩展内圈和法兰。
DDRI-2 1/2 0.0469 in .1562 in .0937 in .0937 in
DDRI-3 0.0550 in .1875 in .0937 in .1094 in
DDRI-4 0.0781 in .2500 in .1094 in .1406 in
DDRI-3332 0.0937 in .1875 in .0937 in .0937 in
DDRI-5 0.0937 in .3125 in .1094 in .1406 in
DDRI-418 0.1250 in .2500 in .0937 in .1094 in
DDRI-518 0.1250 in .3125 in .1094 in .1406 in
DDRI-618 0.1250 in 0.375 in .1094 in .1406 in
DDR-2 0.1250 in 0.375 in .1562 in .1562 in
DDRI-5532 0.1562 in .3125 in .1094 in .1250 in
DDRI-5632 0.1875 in .3125 in .1094 in .1250 in
DDRI-6632 0.1875 in 0.375 in .1250 in .1250 in
DDR-3 0.1875 in 0.5000 in .1960 in .1960 in
DDRI-614 0.2500 in 0.375 in .1250 in .1250 in
DDRI-814 0.2500 in 0.5000 in .1250 in .1875 in
DDR-4 0.2500 in 0.6250 in .1960 in .1960 in
DDRI-1214 0.2500 in .7500 in .2812 in .2812 in
DDRI-8516 0.3125 in 0.5000 in .1562 in .1562 in
DDRI-1038 0.3750 in 0.6250 in .1562 in .1562 in
DDRI-1438 0.3750 in 0.8750 in .2812 in .2812 in
DDRI-1212 0.5000 in .7500 in .1562 in .1562 in
DDRI-1458 0.6250 in 0.8750 in .1562 in .1562 in
DDRI-1634 0.7500 in 1.0000 in .1562 in .1562 in
DDRIF系列法兰屏蔽微型/仪器仪表球轴承
英制系列微型轴承与法兰外径以方便安装。1毫米/0.0400“内径尺寸范围
26毫米/0.8750“外径。他们的目的是在低操作力矩进行适度的径向和推力负荷而
小信封尺寸范围内提供高性能。轴承是在几个价格点提供各种ABEC
类中的铬或不锈钢。
DDRIF-2 1/2 0.0469 in .1562 in .0937 in
DDRIF-3 0.0550 in .1875 in .1094 in
DDRIF-4 0.0781 in .2500 in .1406 in
DDRIF-3332 0.0937 in .1875 in .0937 in
DDRIF-5 0.0937 in .3125 in .1406 in
DDRIF-418 0.1250 in .2500 in .1094 in
DDRIF-518 0.1250 in .3125 in .1406 in
DDRIF-618 0.1250 in 0.375 in .1406 in
DDRF-2 0.1250 in 0.375 in .1562 in
DDRIF-5532 0.1562 in .3125 in .1250 in
DDRIF-5632 0.1875 in .3125 in .1250 in
DDRIF-6632 0.1875 in 0.375 in .1250 in
DDRF-3 0.1875 in 0.5000 in .1960 in
DDRIF-614 0.2500 in 0.375 in .1250 in
DDRIF-814 0.2500 in 0.5000 in .1875 in
DDRF-4 0.2500 in 0.6250 in .1960 in
DDRIF-8516 0.3125 in 0.5000 in .1562 in
DDRIF-1438 0.3750 in 0.8750 in .2812 in
DDRI系列扩展内环微型/仪器仪表球轴承
扩展内圈允许增值设计的灵活性。1毫米/0.0400“内径26毫米/0.8750”外径尺寸范围。
它们的设计进行温和的径向和推力负荷低操作力矩小信封内，同时提供高性能
尺寸。轴承可在各个的ABEC在Chrome或不锈钢类的几个价格点。
DDRI-2 0.0400 in .1250 in .0781 in .0469 in Flanged
Standard
DDRI-2 1/2 0.0469 in .1562 in .0937 in .0625 in Flanged
Standard
DDRI-3 0.0550 in .1875 in .1094 in .0781 in Flanged
Standard
DDRI-4 0.0781 in .2500 in .1250 in .0937 in Flanged
Standard
DDRI-3332 0.0937 in .1875 in .0937 in .0625 in Flanged
Standard
DDRI-5 0.0937 in .3125 in .1406 in .1094 in Flanged
Standard
DDRI-418 0.1250 in .2500 in .1250 in .0937 in Flanged
Standard
DDRI-518 0.1250 in .3125 in .1406 in .1094 in Flanged
Standard
DDRI-618 0.1250 in 0.375 in .1406 in .1094 in Flanged
Standard
DDR-2 0.1250 in 0.375 in .1875 in .1562 in Flanged
Standard
DDRI-5532 0.1562 in .3125 in .1406 in .1094 in Flanged
Standard
DDRI-5632 0.1875 in .3125 in .1406 in .1094 in Flanged
Standard
DDRI-6632 0.1875 in 0.375 in .1562 in .1250 in Flanged
Standard
DDRI-614 0.2500 in 0.375 in .1562 in .1250 in Flanged
Standard
DDRI-814 0.2500 in 0.5000 in .1562 in .1250 in Flanged
Standard
DDRI-8516 0.3125 in 0.5000 in .1875 in .1562 in Flanged
600系列微型/仪器仪表球轴承
600系列是最大的度量风格的缩影/仪器仪表系列。为3mm到9mm口径范围
提供更大的外径和宽度尺寸允许较重的责任从步进电机的应用
滑板车轮。与金属屏蔽或橡胶密封圈。
693 3 mm 8 mm 3 mm 0.15 mm 558 N 180 N 32000 min-1 60000 min-1 67000 min-1
623 3 mm 10 mm 4 mm 0.15 mm 640 N 220 N 32000 min-1 53000 min-1 67000 min-1
694 4 mm 11 mm 4 mm 0.15 mm 967 N 350 N 30000 min-1 43000 min-1 56000 min-1
684 4 mm 9 mm 25 mm 0.10 mm 640 N 225 N 32000 min-1 53000 min-1 63000 min-1
624 4 mm 13 mm 5 mm 0.20 mm 1290 N 490 N 26000 min-1 45000 min-1 53000 min-1
634 4 mm 16 mm 5 mm 0.30 mm 1340 N 525 N 25000 min-1 36000 min-1 43000 min-1
685 5 mm 11 mm 3 mm 0.15 mm 716 N 282 N 26000 min-1 45000 min-1 53000 min-1
695 5 mm 13 mm 4 mm 0.20 mm 1077 N 432 N 24000 min-1 43000 min-1 50000 min-1
605 5 mm 14 mm 5 mm 0.20 mm 1330 N 505 N 25000 min-1 40000 min-1 50000 min-1
625 5 mm 16 mm 5 mm 0.30 mm 1320 N 440 N 24000 min-1 35000 min-1 42000 min-1
635 5 mm 19 mm 6 mm 0.30 mm 2336 N 895 N 22000 min-1 32000 min-1 40000 min-1
696 6 mm 15 mm 5 mm 0.15 mm 1082 N 442 N 24000 min-1 40000 min-1 45000 min-1
606 6 mm 17 mm 6 mm 0.30 mm 2263 N 845 N 23000 min-1 38000 min-1 45000 min-1
626 6 mm 19 mm 6 mm 0.30 mm 2522 N 1057 N 22000 min-1 32000 min-1 38000 min-1
687 7 mm 14 mm 3.5 mm 0.20 mm 898 N 458 N 20000 min-1 31000 min-1 40000 min-1
697 7 mm 17 mm 5 mm 0.30 mm 1605 N 720 N 22000 min-1 36000 min-1 43000 min-1
607 7 mm 19 mm 6 mm 0.30 mm 2838 N 1078 N 22000 min-1 32000 min-1 38000 min-1
627 7 mm 22 mm 7 mm 0.30 mm 3282 N 1356 N 20000 min-1 34000 min-1 36000 min-1
688 8 mm 16 mm 4 mm 0.20 mm 1252 N 592 N 22000 min-1 36000 min-1 43000 min-1
698 8 mm 19 mm 6 mm 0.30 mm 2237 N 917 N 22000 min-1 36000 min-1 43000 min-1
608 8 mm 22 mm 7 mm 0.30 mm 3369 N 1363 N 20000 min-1 30000 min-1 36000 min-1
628 8 mm 24 mm 8 mm 0.30 mm 3350 N 1400 N 20000 min-1 24000 min-1 32000 min-1
689 9 mm 17 mm 4 mm 0.20 mm 1378 N 797 N 19000 min-1 28000 min-1 36000 min-1
609 9 mm 24 mm 7 mm 0.30 mm 3435 N 1430 N 20000 min-1 32000 min-1 36000 min-1
629 9 mm 26 mm 8 mm 0.30 mm 4557 N 1955 N 19000 min-1 30000 min-1 34000 min-1
60/2.5/P5 2.5 mm 8 mm 2.8 mm N/A 319 N 106 N N/A 67000 r/min 80000 r/min
604 4 mm 12 mm 4 mm N/A 806 N 280 N N/A 53000 r/min 63000 r/min
607 7 mm 19 mm 6 mm N/A 1720 N 620 N N/A 38000 r/min 45000 r/min
608 8 mm 22 mm 7 mm N/A 3250 N 1370 N N/A 36000 r/min 43000 r/min
609 9 mm 24 mm 7 mm N/A 3710 N 1660 N N/A 32000 r/min 38000 r/min】
