| 品牌 | MCGILL | 型号 | CCYR3/4S | 旧型号 | CCYR3/4S |
| 内径 | 6.35（mm） | 外径 | 19.05（mm） | 厚度 | 14.288（mm） |
| 重量 | 1（kg） | 保持架及其材料 | J钢板冲压 | 使用特性 | 高温 |
| 用途 | 通用 | 滚动体列数 | 单列 | 滚道类型 | 直线滚道 |
| 样品或现货 | 现货 | 轴承材质 | 高碳铬轴承钢（全淬透型)(GCr15) | 滚动体类型 | 滚针 |
| 角度 | 15度 | 密封盖 | 双面密封 | 滚动体 | 钢球 |
| 类型 | 英制滚针滚轮轴承 | 加工定制 | 是 | 工作原理 | 滚动 |
MCGILL滚针滚轮轴承CCYR3/4S
内径：6.35mm
外径：19.05mm
宽度：14.288mm
型号：MCGILL滚针滚轮轴承CCYR3/4S
类型：MCGILL滚针滚轮轴承CCYR3/4S
品牌：MCGILL滚针滚轮轴承CCYR3/4S
备注：MCGILL滚针滚轮轴承CCYR3/4S
Description:
Similar as NATV..PP series, but in inch dimensions. Black oxide treated bearing steel.
| Mcgill Bearing Code | Dimensions(mm) |
Cr Dynamic (KN) |
Cor Static (KN) |
|||||||
| D | C | B | d | a | ||||||
| CYR 3/4 | CYR 3/4 S | CCYR 3/4 S |
0.750 19.05 |
0.500 12.7 |
.5625 14.288 |
0.250 6.350 |
39/64 15.478 |
5.2 | 11.9 | |
| CYR 7/8 | CYR 7/8 S | CCYR 7/8 S |
0.875 22.225 |
0.500 12.7 |
.5625 14.288 |
0.250 6.350 |
39/64 15.478 |
5.2 | 11.9 | |
| CYR 1 | CYR 1 S | CCYR 1 S |
1.000 25.4 |
0.625 15.875 |
0.6875 17.463 |
0.3125 7.938 |
25/32 19.844 |
7.0 | 17.7 | |
| CYR 1 1/8 | CYR 1 1/8 S | CCYR 1 1/8 S |
1.125 28.575 |
0.625 15.875 |
0.6875 17.463 |
0.3125 7.938 |
25/32 19.844 |
7.0 | 17.7 | |
| CYR 1 1/4 | CYR 1 1/4 S | CCYR 1 1/4 S |
1.250 31.75 |
0.750 19.05 |
0.8125 20.638 |
0.375 9.525 |
63/64 25.003 |
12.3 | 24.6 | |
| CYR 1 3/8 | CYR 1 3/8 S | CCYR 1 3/8 S |
1.375 34.925 |
0.750 19.05 |
0.8125 20.638 |
0.375 9.525 |
63/64 25.003 |
12.3 | 24.6 | |
| CYR 1 1/2 | CYR 1 1/2 S | CCYR 1 1/2 S |
1.500 38.1 |
0.875 22.225 |
0.9375 23.813 |
0.4375 11.113 |
1 3/32 27.781 |
14.0 | 32.6 | |
| CYR 1 5/8 | CYR 1 5/8 S | CCYR 1 5/8 S |
1.625 41.275 |
0.875 22.225 |
0.9375 23.813 |
0.4375 11.113 |
1 3/32 27.781 |
14.0 | 32.6 | |
| CYR 1 3/4 | CYR 1 3/4 S | CCYR 1 3/4 S |
1.750 44.45 |
1.000 25.4 |
1.0625 26.988 |
0.500 12.7 |
1 1/4 31.75 |
20.0 | 45.8 | |
| CYR 1 7/8 | CYR 1 7/8 S | CCYR 1 7/8 S |
1.875 47.625 |
1.000 25.4 |
1.0625 26.988 |
0.500 12.7 |
1 1/4 31.75 |
20.0 | 45.8 | |
| CYR 2 | CYR 2 S | CCYR 2 S |
2.000 50.8 |
1.250 31.75 |
1.3125 33.338 |
0.625 15.875 |
1 13/32 35.719 |
25.2 | 61.2 | |
| CYR 2 1/4 | CYR 2 1/4 S | CCYR 2 1/4 S |
2.250 57.15 |
1.250 31.75 |
1.3125 33.338 |
0.625 15.875 |
1 13/32 35.719 |
25.2 | 61.2 | |
| CYR 2 1/2 | CYR 2 1/2 S | CCYR 2 1/2 S |
2.500 63.5 |
1.500 38.1 |
1.5625 39.688 |
0.750 19.05 |
1 11/16 42.863 |
36.5 | 95.2 | |
| CYR 2 3/4 | CYR 2 3/4 S | CCYR 2 3/4 S |
2.750 69.85 |
1.500 38.1 |
1.5625 39.688 |
0.750 19.05 |
1 11/16 42.863 |
36.5 | 95.2 | |
| CYR 3 | CYR 3 S | CCYR 3 S |
3.000 76.2 |
1.750 44.45 |
1.8125 46.038 |
1.000 25.4 |
2 1/8 53.975 |
48.9 | 144.1 | |
| CYR 3 1/4 | CYR 3 1/4 S | CCYR 3 1/4 S |
3.250 82.55 |
1.750 44.45 |
1.8125 46.038 |
1.000 25.4 |
2 1/8 53.975 |
48.9 | 144.1 | |
| CYR 3 1/2 | CYR 3 1/2 S | CCYR 3 1/2 S |
3.500 88.9 |
2.000 50.8 |
2.0625 52.388 |
1.125 28.575 |
2 7/16 61.913 |
71.0 | 183.0 | |
| CYR 4 | CYR 4 S | CCYR 4 S |
4.000 101.6 |
2.250 57.15 |
2.3125 58.738 |
1.250 31.75 |
2 51/64 71.041 |
93.4 | 259.0 | |
| CYR 5 S | CCYR 5 S |
5.000 127 |
2.750 69.85 |
2.875 73.025 |
1.750 44.45 |
3 9/16 90.488 |
145.0 | 393.1 | ||
| CYR 6 S | CCYR 6 S |
6.000 152.40 |
3.250 82.55 |
3.375 85.725 |
2.250 57.15 |
4 15/32 113.51 |
186.9 | 465.4 | ||
| CYR 7 S | CCYR 7 S |
7.000 177.8 |
3.75 95.25 |
3.875 98.425 |
2.750 69.85 |
5 3/16 131.763 |
234.8 | 618.6 | ||
| CYR 8 S | CCYR 8 S |
8.000 203.2 |
4.25 107.95 |
4.500 114.30 |
3.255 82.677 |
4 3/8 111.13 |
287.2 | 833.6 | ||
| CYR 9 S | CCYR 9 S |
9.000 228.6 |
4.75 120.65 |
5.000 127.0 |
3.755 95.377 |
5 1/6 131.23 |
352.8 | 1061.1 | ||
| CYR 10 S | CCYR 10 S |
10.000 254.0 |
5.25 133.35 |
5.5 139.7 |
4.255 108.08 |
5 15/32 138.91 |
409.8 | 1247.0 | ||
