Main Dimensions & Performance DataDownload data sheet
d
60 mm
Bore diameter
L
195 mm
Flange width
U
78.4 mm
Total height unit
Cr
82,000 N
Basic dynamic load rating, radial
C0r
52,000 N
Basic static load rating, radial
Cur
2,700 N
Fatigue load limit, radial
6.73 kg
Weight
Dimensions
A
49.5 mm
Height housing
A1
22 mm
Thickness of flange
A2
33 mm
Distance raceway
V
170 mm
Shoulder diameter housing
Q
M6
Connection thread lubrication
d3
89 mm
Outside diameter eccentric locking collar
Mounting dimensions
J
150 mm
Distance fixing bore
N
23 mm
Fixing bore
n
4
Number of screwing holes
Additional information
1
Number of housings
CJO12
Housing
GNE60-XL-KRR-B
Bea
