Fw
30 mm
Under roller diameter
D
37 mm
Outside diameter
C
38 mm
Width, outer ring
Cr
37,500 N
Basic dynamic load rating, radial
C0r
79,000 N
Basic static load rating, radial
Cur
10,300 N
Fatigue load limit, radial
nG
8,600 1/min
Limiting speed
nϑr
6,200 1/min
Reference speed
76.5 g
Weight
Dimensions
rmin
0.8 mm
Minimum chamfer dimension
Temperature range
Tmin
-30 °C
Operating temperature min.
Tmax
140 °C
Operating temperature max.
Additional information
SD30X37X4
Sealing ring
G30X37X4
Sealing ring 2
LR25X30X38,5
Suitable inner rings LR
IR25X30X38,5-XL
S
