轴径 |
轴承型号 Bearing Designation |
外形尺寸 Boudary Dimensions |
基本额定负荷 Basic Load Rating |
极限转速Limiting Speed |
||||
|
Shaft |
现行的 Current |
被取代的Original Code |
Fw |
Ew |
Bc |
动Cr Dynamic |
静Cor Static |
油润滑 Oil |
|
Diameter |
||||||||
|
mm |
mm |
N |
rpm |
|||||
|
5 |
K5X8X8 |
29241/5 |
5 |
8 |
8 |
2300 |
1880 |
37000 |
|
K5X8X10 |
39241/5 |
5 |
8 |
10 |
2800 |
2450 |
37000 |
|
|
6 |
K6X9X8 |
29241/6 |
6 |
9 |
8 |
2560 |
2240 |
35000 |
|
K6X9X10 |
39241/6 |
6 |
9 |
10 |
3300 |
3100 |
35000 |
|
|
K6X10X13 |
49241/6 |
6 |
10 |
13 |
3500 |
2800 |
33000 |
|
|
7 |
K7X10X8 |
29241/7 |
7 |
10 |
8 |
2750 |
2550 |
32000 |
|
K7X10X10 |
39241/7 |
7 |
10 |
10 |
3350 |
3400 |
32000 |
|
|
8 |
K8X11X8 |
29241/8 |
8 |
11 |
8 |
3000 |
2900 |
30000 |
|
K8X11X10 |
39241/8 |
8 |
11 |
10 |
3830 |
3950 |
30000 |
|
|
K8X11X13 |
49241/8 |
8 |
11 |
13 |
5000 |
5700 |
30000 |
|
|
K8X12X10 |
29242/8 |
8 |
12 |
10 |
4900 |
4600 |
30000 |
|
|
9 |
K9X12X10 |
39241/9 |
9 |
12 |
10 |
4200 |
4700 |
30000 |
|
K9X12X13 |
49241/9 |
9 |
12 |
13 |
5500 |
6700 |
30000 |
|
|
10 |
K10X13X10 |
39241/10 |
10 |
13 |
10 |
4500 |
5250 |
27000 |
|
K10X13X13 |
39241/10 |
10 |
13 |
13 |
6000 |
7600 |
27000 |
|
|
K10X13X16 |
— |
10 |
13 |
16 |
6300 |
7800 |
27000 |
|
|
K10X14X10 |
29242/10 |
10 |
14 |
10 |
7000 |
7900 |
27000 |
|
|
K10X14X13 |
39242/10 |
10 |
14 |
13 |
8000 |
9100 |
26000 |
|
|
K10X16X12 |
19244/10 |
10 |
16 |
12 |
7000 |
9300 |
27000 |
|
|
12 |
K12X15X9 |
— |
12 |
15 |
9 |
4120 |
5210 |
25000 |
|
K12X15X10 |
39241/12 |
12 |
15 |
10 |
4320 |
5730 |
25000 |
|
|
K12X15X13 |
49241/12 |
12 |
15 |
13 |
6000 |
8100 |
25000 |
|
|
K12X16X8 |
19242/12 |
12 |
16 |
8 |
4200 |
4700 |
25000 |
|
|
K12X16X10 |
29242/12 |
12 |
16 |
10 |
6000 |
6900 |
25000 |
|
|
K12X16X13 |
39242/12 |
12 |
16 |
13 |
7900 |
9200 |
25000 |
|
|
K12X17X13 |
59242/12 |
12 |
17 |
13 |
9300 |
10000 |
24000 |
|
|
K12X18X12 |
19244/12 |
12 |
18 |
12 |
9800 |
8000 |
24000 |
|
|
K12X15X20 |
K12X15X20 |
12 |
15 |
20 |
8200 |
12000 |
25000 |
|
|
14 |
K14X17X10 |
— |
14 |
17 |
10 |
5100 |
6800 |
23000 |
|
K14X17X17 |
— |
14 |
17 |
17 |
9300 |
14000 |
23000 |
|
|
K14X18X10 |
29241/14 |
14 |
18 |
10 |
6800 |
8300 |
23000 |
|
|
K14X18X13 |
39241/14 |
14 |
18 |
13 |
8100 |
9800 |
23000 |
|
|
K14X18X14 |
— |
14 |
18 |
14 |
9200 |
12000 |
23000 |
|
|
K14X18X15 |
49241/14 |
14 |
18 |
15 |
10000 |
13000 |
23000 |
|
|
K14X18X17 |
59241/14 |
14 |
18 |
17 |
10500 |
13900 |
23000 |
|
|
K14X20X12 |
19243/14 |
14 |
20 |
12 |
9900 |
10500 |
22000 |
|
|
15 |
K15X18X14 |
— |
15 |
18 |
14 |
7500 |
11000 |
23000 |
|
K15X18X17 |
— |
15 |
18 |
17 |
9600 |
15900 |
23000 |
|
|
K15X19X10 |
29242/15 |
15 |
19 |
10 |
7200 |
9000 |
22000 |
|
|
K15X19X13 |
39241/15 |
15 |
19 |
13 |
8300 |
9800 |
22000 |
|
|
K15X19X17 |
59241/15 |
15 |
19 |
17 |
10300 |
15000 |
22000 |
|
|
K15X19X24 |
79241/15 |
15 |
19 |
24 |
12800 |
20100 |
22000 |
|
|
K15X19X13 |
29242/15 |
15 |
20 |
13 |
9700 |
11000 |
22000 |
|
|
K15X21X12 |
19243/15 |
15 |
21 |
12 |
10000 |
13000 |
22000 |
|
|
K15X21X15 |
39242/15 |
15 |
21 |
15 |
13800 |
16000 |
22000 |
|
|
K15X21X21 |
— |
15 |
21 |
21 |
18000 |
24000 |
22000 |
|
