推力角接触球轴承ZKLN2052-2RS
增加公差，双向，两侧唇密封








		组件
相邻结构设计 相邻结构设计		d 20 mm    公差: -0,01 D 52 mm    公差: -0,013 B 28 mm    公差: -0,25   Da max 43 mm  d1 34,5 mm  da min 25 mm  r1 min 0,6 mm  rmin 0,3 mm    m 0,31 kg    质量 Ca 26000 N    基本额定动载荷，轴向 C0a 47000 N    基本额定静载荷，轴向 nG Fett 3000 1/min    脂润滑时的极限转速 MRL 0,3 Nm    轴承摩擦力矩 caL 650 N/μm    轴向刚度 ckL 140 Nm/mrad    倾斜刚度 Mm 0,273 kg x cm^2    旋转内圈的质量惯性矩   5 μm    轴向跳动 丝杠支撑轴承配置的轴向跳动基于内圈旋转。   ZM20, AM20    推荐 INA 锁紧螺母的代号       锁紧螺母不在供货范围。 MA 18 Nm    扭紧力矩 只适用于INA精密锁紧螺母   9079 N    轴向预载



主轴轴承：高性能和高精度的高速推力轴承

BAX系列的FAG高速推力轴承的使用使得先前只有主轴轴承才能达到的转速参数，现在在主轴上使用推力轴承和圆柱滚子轴承的组合同样可以达到。同时，这种轴承组合以轴承支撑中的轴向和径向载荷的分离为特征。这就意味着没有必要关注任何倾斜的影响，所以当联合载荷出现时运动学特性不会受到影响。这使得轴承支撑更加可靠。用户也受益于高刚度带来的高运行精确度。非常出色的承载和旋转能力，保证了良好的切削性能和高生产率。



FAG主轴轴承部分型号：

HCS7012C-T-P4S-UL

HCS7012E-T-P4S-UL

HCS7013C-T-P4S-UL

HCS7013E-T-P4S-UL

HCS7014C-T-P4S-UL

HCS7014E-T-P4S-UL

HCS7020E-T-P4S-DUL

HCS7020E-T-P4S-UL

HCS71905E-T-P4S-UL

HCS71906C-T-P4S-UL

HCS71910E-T-P4S-UL

HCS71911C-T-P4S-UL

HCS71911E-T-P4S-UL

HCS71912C-T-P4S-UL

HSS7009C.T.P4S.DUL

HCS71912E-T-P4S-UL

HCS71913C-T-P4S-UL

HCS71916E-T-P4S-UL

HS7004C-T-P4S-UL

HS7005C-T-P4S-UL

HS7006C-T-P4S-UL

HS7009C-T-P4S-UL

HS7010C-T-P4S-UL

HS7012C-T-P4S-UL

HS7013E-T-P4S-UL

HS7016C-T-P4S-UL

HS7016E-T-P4S-UL

HS7019C-T-P4S-UL

HS71907C-T-P4S-UL

HS71911C-T-P4S-UL

HS71914C-T-P4S-UL

HS71920E-T-P4S-UL

HS71922E-T-P4S-UL

HSS7002C-T-P4S-UL

HSS7003C-T-P4S-UL

HSS7004C-T-P4S-UL

HSS7006C-T-P4S-UL

HSS7007C-T-P4S-UL

HSS7008C-T-P4S-UL

HSS7008E-T-P4S-UL

HSS7009C-T-P4S-DUL

HSS7009C-T-P4S-UL

HSS7009E-T-P4S-UL

HSS7010C-T-P4S-UL

HSS7010E-T-P4S-UL

HSS7012C-T-P4S-UL

HSS7012E-T-P4S-UL

HSS7013C-T-P4S-UL

HSS7013E-T-P4S-UL

HSS7014C-T-P4S-UL

HSS7014E-T-P4S-UL

HSS7018C-T-P4S-UL

HSS71900C-T-P4S-UL

HSS71908E-T-P4S-UL

HSS71909E-T-P4S-UL

HSS71910C-T-P4S-UL

HSS71911C-T-P4S-UL

HSS71912C-T-P4S-UL

HSS71914C-T-P4S-UL

HSS71914E-T-P4S-UL

HSS71917C-T-P4S-UL

HSS71918C-T-P4S-UL

HSS71920E-T-P4S-UL

XC7010E-T-P4S-UL

XC7011E-T-P4S-UL

XCB71914E-2RSD-T-P4S-UL

XCS7009C-T-P4S-UL

XCS7009E-T-P4S-UL

XCS7012E-T-P4S-UL

XCS7014C-T-P4S-UL

XCS7014E-T-P4S-QUL

XCS7014E-T-P4S-UL





INA轴承库存型号：

ZARF 2575 TV A

ZARF 2590 TV A

ZARF 3080 TV A

ZARF 35110 L TN A

ZARF 35110 TV A

ZARF 3590 L TV A

ZARF 3590 TV A

ZARF 45130 TV A

ZARF 50115 L TV A

ZARF 50115 TN

ZARF2575-L-TV-A

ZARF2590-A-C3

ZARF2590-TV-A

ZARF3080-TV-A

ZARF35110

ZARF3590-L-TV-A

ZARF3590-TV-A

ZARF40100-TV-A

ZARF40115-TV-A

ZARF45130-TV

ZARF45130-TV-A

ZARF45130-TV-A.E55ES

ZARF55145-TV-A

ZARF60150-TV-A

ZARN 2062 TN A

ZARN 2557 TN

ZARN 3062 TN A

ZARN 3080 TN

ZARN 4075 L TN A

ZARN 4090 TN A

ZARN 75155 TN

ZARN2557-TV-A

ZARN3585-TV-A

ZARN50110-TV-A

ZARN5090-TV-A

ZARN60120-TV-A

ZKLF 1560 2RS

ZKLF 1762 2RS

ZKLF 1762 2RS 2AP

ZKLF 2068 2RS 2AP

ZKLF 2575 2RS

ZKLF 30100 2RS

ZKLF 30100 2Z

ZKLF 3080 2RS

ZKLF 3080 2RS 2AP

ZKLF 3590 2RS

ZKLF 40100 2RS

ZKLF1255-2RS

ZKLF1560-2RS

ZKLF1762-2RS

ZKLF2068-2RS#E

ZKLF30100-2RS

ZKLF30100-2Z

ZKLF30802RS

ZKLF3080-2RS

ZKLF3080-2RS

ZKLF40115-2RS

ZKLF50115.2RSR-2AP

ZKLN 1242 2RS

ZKLN 1242 2RS 2AP

ZKLN 1545 2RS

ZKLN 2052 2RS

ZKLN 2052 2RS 2AP

ZKLN 2557 2RS

ZKLN 3062 2RS

ZKLN 3572 2RS

ZKLN 3572 2Z

ZKLN 4075 2RS

ZKLN0624-2RS

ZKLN1242-2RS

ZKLN1545-2RS

ZKLN2052-2RS

ZKLN2557-2RS

ZKLN3062.2RS.2AP

ZKLN3062.DAC

ZKLN3072.2Z-2AP
