镇江FYB飞亚轴承KRV3214制药机械洗瓶机摆动端螺栓滚轮轴承

镇江FYB飞亚轴承KRV3214制药机械洗瓶机摆动端螺栓滚轮轴承尺寸|轴承规格参数|轴承报价

内径：镇江FYB飞亚轴承KRV3214制药机械洗瓶机摆动端螺栓滚轮轴承
外径：镇江FYB飞亚轴承KRV3214制药机械洗瓶机摆动端螺栓滚轮轴承
宽度：镇江FYB飞亚轴承KRV3214制药机械洗瓶机摆动端螺栓滚轮轴承
型号：镇江FYB飞亚轴承KRV3214制药机械洗瓶机摆动端螺栓滚轮轴承

类型：滚针轴承

品牌：镇江FYB飞亚轴承KRV3214制药机械洗瓶机摆动端螺栓滚轮轴承

备注：滚针轴承









• 轻系列带螺栓滚轮滚针轴承外形尺寸



轴承型号		D	d1	C	B1	B2	B3	G	G1	M	M1	C1	rsmin
KR	KRV
KR22	KRV22	22	10	12	36	23	-	M10x1.25	12	4	-	0.6	0.3
KR22A	KRV22A	22	10	12	36	23	-	M10x1	12	4	-	0.6	0.3
KR26	KRV26	26	10	12	36	23	-	M10x1.25	12	4	-	0.6	0.3
KR26A	KRV26A	26	10	12	36	23	-	M10x1	12	4	-	0.6	0.3
KR30	KRV30	30	12	14	40	25	6	M12x1.5	13	6	3	0.6	0.6
KR32	KRV32	32	12	14	40	25	6	M12x1.5	13	6	3	0.6	0.6
KR35	KRV35	35	16	18	52	32.5	8	M16x1.5	17	6	3	0.8	0.6
KR40	KRV40	40	18	20	58	36.5	8	M18x1.5	19	6	3	0.8	1.0
KR547	KRV47	47	20	24	66	40.5	9	M20x1.5	21	8	4	0.8	1.0
KR52	KRV52	52	20	24	66	40.5	9	M20x1.5	21	8	4	0.8	1.0
KR62	KRV62	62	24	29	80	49.5	11	M24x1.5	25	8	4	0.8	1.0
KR72	KRV72	72	24	29	80	49.5	11	M24x1.5	25	8	4	0.8	1.0
KR80	KRV80	80	30	35	100	63	15	M30x1.5	32	8	4	1.0	1.0

• 重系列带螺栓滚轮滚针轴承外形尺寸



轴承型号		D	d1	C	B1	B2	B3	G	G1	C1	rsmin
KR	KRV
KR19 10	KRV19 10	19	10	11	34	22	-	M10x1.25	12	0.5	0.3
KR240 12	KRV24 12	24	12	14	41	26	-	M12x1.5	14	0.5	0.3
KR30 14	KRV3214	32	14	17	48	30	7	M14x1.5	16	0.5	0.6
KR37 16	KRV37 16	37	16	20	56	35	8	M16x1.5	18	0.5	1
KR42 20	KRV42 20	42	20	22	65	41	10	M20x1.5	21	1	1
KR47 24	KRV47 24	47	24	25	75	48	11	M24x1.5	25	1	1
KR58 30	KRV58 30	58	30	32	93	59	14	M30x1.5	30	1	1
KR72 36	KRV72 36	72	36	38	116	76	17	M36x3	41	1	1
KR85 42	KRV85 42	85	42	46	125	87	20	M42x3	46	1	1.5
KR100 48	KRV100 48	100	48	54	156	100	23	M48x3	53	1	1.5
KR110 56	KRV110 56	110	56	61	178	115	-	M56X4	61	1	2
KR125 64	KRV125 64	125	64	69	200	129	-	M64x4	68	1	2
KR140 72	KRV140 72	140	72	76	222	143	-	M72x4	73	2	2.5



• KRV32
  KRV3214
  KRV35
  KRV3716
  KRV40
  KRV4220
  KRV47
  KRV4722
  KRV4724
  KRV50
  KRV52
  KRV5821
  KRV5830
  KRV5830L
  KRV62
  KRV72
  KRV7236
  KRV80
  KRV80L
  KRV8035
  KRV85
  KRV8542
  KRV8542L
  KRV8936
  KRV90
  KRV90L
  KRV90E
  KRV9036
  KRV9045
  KRV9050
  KRV100
  KRV10036
  KRV10048
  KRV11056
  KRV12564
  KRV14072
  KRV14960A
  KRV16080
  KRV19080
  KRV19080T
  KRV19080TA
  KRV19080TB
  KRV21090
  KRV240100

• 外型尺寸mm					轴承型号
  					圆弧面滚轮滚针类			圆柱面滚轮滚针类		滚轮滚针类
  外径D	螺杆直径d	外圈高度C	螺栓总长B	螺牙G	KR	KRV		KR…X	KRV…X	NUKR	NUKR…X
  30	12	14	40	12×1.5	KR30	KRV30		KR30X	KRV30X	NUKR30	NUKR30X
  	12	14	90	12×1.5	KR30L	KRV30L		KR30XL	KRV30XL
  	12	14	60	12×1.5					KRV30XL1
  	12	14	55	12×1.5					KRV30XL2
  32	12	21.2	47	12×1.5					KRV32V
  	12	21.2	47	12×1.5					KRV32XL
  	12	14	40	12×1.5	KR32	KRV32		KR32X	KRV32X	NUKR32	NUKR32X
  	14	17	48	14×1.5	KR3214	KRV3214		KR3214X	KRV3214X
  35	16	18	52	16×1.5	KR35	KRV35		KR35X	KRV35X	NUKR35	NUKR35X
  	16	18	55	16×1.5					KRV35XL
  37	16	20	56	16×1.5	KR3716	KRV3716		KR3716X	KRV3716X
  38	16	22	62	16×1.5					KRV3816X
  40	18	20	58	18×1.5	KR40	KRV40		KR40X	KRV40X	NUKR40	NUKR40X
  42	20	22	65	18×1.5	KR4220	KRV4220		KR4220X	KRV4220X
  47	20	24	66	20×1.5	KR47	KRV47		KR47X	KRV47X	NUKR47	NUKR47X
  	22	25	75	20×1.5	KR4722	KRV4722		KR4722X	KRV4722X
  	24	25	75	20×1.5	KR4724	KRV4724		KR4724X	KRV4724X
  50	22	24	71	24×1.5	KR50	KRV50		KR50X	KRV50X	NUKR50	NUKR50X
  52	20	24	66	20×1.5	KR52	KRV52		KR52X	KRV52X	NUKR52	NUKR52X
  58	21	28	85	20×1.5	KR5821	KRV5821		KR5821X	KRV5821X
  	30	32	93	30×1.5	KR5830	KRV5830		KR5830X	KRV5830X
  	30	32	130	30×1.5	KR5830L	KRV5830L		KR5830XL	KRV5830XL
  62	24	29	80	24×1.5	KR62	KRV62		KR62X	KRV62X	NUKR62	NUKR62X
  72	24	29	80	24×1.5	KR72	KRV72		KR72X	KRV72X	NUKR72	NUKR72X
  	36	38	116	36×3	KR7236	KRV7236		KR7236X	KRV7236X
  76	38	43.66	108.74	36×2					KRV7638X
  80	30	35	100	30×1.5	KR80	KRV80		KR80X	KRV80X	NUKR80	NUKR80X
  	30	35	120	30×1.5	KR80L	KRV80L		KR80XL	KRV80XL
  	35	50.4	122	30×1.5	KR8035	KRV8035		KR8035X	KRV8035X
  	30	27	100	30×1.5							NUKR80XL
  	30	35	130	30×2					KRV80EE
  85	30	35	100	30×1.5	KR85	KRV85		KR85X	KRV85X	NUKR85	NUKR85X
  	42	46	135	42×3	KR8542	KRV8542		KR8542X	KRV8542X
  	42	46	125	42×3	KR8542L	KRV8542L		KR8542XL	KRV8542XL
  86	24	29	80	24×1.5						NUKR86K	NUKR86KX
  89	36	50	128	36×3	KR8936	KRV8936		KR8936X	KRV8936X
  90	30	35	100	30×1.5	KR90	KRV90		KR90X	KRV90X	NUKR90	NUKR90X
  	30	35	232	30×1.5	KR90L	KRV90L		KR90XL	KRV90XL
  	40	35	150	30×1.5					KRV9040X
  	30	35	136	30×1.5		KRV90E			KRV90EX
  	36	38	128	36×3	KR9036	KRV9036		KR9036X	KRV9036X
  	45	50	125	45×3	KR9045	KRV9045		KR9045X	KRV9045X
  	50	35	130	36×3	KR9050	KRV9050		KR9050X	KRV9050X
  100	36	43	120	36×1.5	KR100	KRV100		KR100X	KRV100X	NUKR100	NUKR100X
  	36	45	120	36×3	KR10036	KRV10036		KR10036X	KRV10036X
  	48	54	156	48×3	KR10048	KRV10048		KR10048X	KRV10048X
  110	56	61	178	56×4	KR11056	KRV11056		KR11056X	KRV11056X
  	30	35	100	30×1.5					KRV11030X
  120	42	50	140	42×1.5						NUKR120	NUKR120X
  	42	40	170	36×1.5							NUKR120XL
  125	60	69	180	57×2.2	非螺纹尾部卡槽安装，位置15				KRV12560X
  	64	69	200	64×4	KR12564		KRV12564	KR12564X	KRV12564X
  140	48	57	160	48×1.5						NUKR140	NUKR140X
  	72	76	222	72×3	KR14072		KRV14072	KR14072X	KRV14072X
  149	60	69	102	∮64	KR14960A		KRV14960A	KR14960XA	KRV1496X0A	短头光杆无螺纹
  	70	69	102	∮60					JS9804.5
  150	52	60	170	52×1.5						NUKR150		NUKR150X
  160	56	63	180	56×3						NUKR160		NUKR160X
  	80	83	246	80×4	KR16080		KRV16080	KR16080X	KRV16080X
  170	60	66	190	60×3						NUKR170		NUKR170X
  180	64	72	200	64×3						NUKR180		NUKR180X
  	68	63	293	68×2						RK180		RK180X
  190	80	99	262	80×4	KR19080		KRV19080	KR19080X	KRV19080X
  	80	100	458	连轴型无螺纹	KR19080T		KRV19080T	KR19080XT	KRV19080XT
  	80	95	448		KR19080TA		KRV19080TA	KR19080XTA	KRV19080XTA
  	80	100	465		KR19080TB		KRV19080TB	KR19080XTB	KRV19080XTB
  	80	100	438						KRV19080XTC
  	80	100	475						KRV19080XTD
  210	90	111	292	90×4	KR21090		KRV21090	KR21090X	KRV21090X
  240	100	128	328	100×4	KR240100		KRV240100	KR240100X	KRV240100X

•
