德国FAG轴承B71905C.T.P4S.UL精密机床主轴轴承B71905-C-T-P4S-UL

德国FAG轴承B71905C.T.P4S.UL精密机床主轴轴承B71905-C-T-P4S-UL

  • 型号：
  • B71905C.T.P4S.UL
  • 品牌：
  • FAG轴承
  • 系列：
  • 内径d：
  • mm
  • 外径D：
  • mm
  • 厚度B：
  • mm
德国FAG轴承B71905C.T.P4S.UL精密机床主轴轴承B71905-C-T-P4S-UL参数

参数信息

品牌
FAG
型号
B71905-C-T-P4S-UL
厚度（mm）
9mm
颜色分类
乳白色
是否标准件
是
滚动体列数
单列
是否进口
是
滚动轴承座材质：
轴承钢
内径（mm）
25



图文详情

品牌 FAG 型号 主轴轴承B71905-C-T-P4S-UL 加工定制 是
是否标准件 标准件 样品或现货 现货 是否进口 进口
类型 钢球 用途 角接触球轴承 材质 碳钢
尺寸 主轴轴承B71905-C-T-P4S-UL



FAG B71905C.T.P4S.UL精密机床主轴轴承B71905-C-T-P4S-UL


调节，成对安装，接触角 α = 15°，限制公差

  FAG轴承B71905-C-T-P4S-UL

FAG轴承B71905-C-T-P4S-UL (2)

FAG轴承B71905-C-T-P4S-UL (3)

FAG轴承B71905-C-T-P4S-UL (4)



主轴轴承 B71905-C-T-P4S, 调节，成对安装，接触角 α = 15°，限制公差
径向载荷单向轴向载荷无密封脂润滑油润滑
主轴轴承 B71905-C-T-P4S, 调节，成对安装，接触角 α = 15°，限制公差
主轴轴承 B71905-C-T-P4S, 调节，成对安装，接触角 α = 15°，限制公差


d 25 mm

D 42 mm

B 9 mm


a 9 mm

Da H12 38,5 mm

da h12 29 mm

r1 min 0,3 mm

ra max 0,3 mm

ra1 max 0,3 mm

rmin 0,3 mm


m 0,043 kg
  质量
Cr 8300 N
  基本额定动载荷，径向
C0r 4050 N
  基本额定静载荷，径向
f0 15,5

nG Fett 36000 1/min
  脂润滑时的极限转速
nG Öl 56000 1/min
  最少油润滑时的极限转速
Cur 415 N
  疲劳极限载荷，径向

  FAG B71900C.T.P4S.UL FAG B71900-C-T-P4S-UL
FAG B71900E.T.P4S.UL FAG B71900-E-T-P4S-UL
FAG B71901C.T.P4S.UL FAG B71901-C-T-P4S-UL
FAG B71901E.T.P4S.UL FAG B71901-E-T-P4S-UL
FAG B71902C.T.P4S.UL FAG B71902-C-T-P4S-UL
FAG B71902E.T.P4S.UL FAG B71902-E-T-P4S-UL
FAG B71903C.T.P4S.UL FAG B71903-C-T-P4S-UL
FAG B71903E.T.P4S.UL FAG B71903-E-T-P4S-UL
FAG B71904C.T.P4S.UL FAG B71904-C-T-P4S-UL
FAG B71904E.T.P4S.UL FAG B71904-E-T-P4S-UL
FAG B71905C.T.P4S.UL FAG B71905-C-T-P4S-UL
FAG B71905E.T.P4S.UL FAG B71905-E-T-P4S-UL
FAG B71906C.T.P4S.UL FAG B71906-C-T-P4S-UL
FAG B71906E.T.P4S.UL FAG B71906-E-T-P4S-UL
FAG B71907C.T.P4S.UL FAG B71907-C-T-P4S-UL
FAG B71907E.T.P4S.UL FAG B71907-E-T-P4S-UL
FAG B71908C.T.P4S.UL FAG B71908-C-T-P4S-UL
FAG B71908E.T.P4S.UL FAG B71908-E-T-P4S-UL
FAG B71909C.T.P4S.UL FAG B71909-C-T-P4S-UL
FAG B71909E.T.P4S.UL FAG B71909-E-T-P4S-UL
FAG B71910C.T.P4S.UL FAG B71910-C-T-P4S-UL
FAG B71910E.T.P4S.UL FAG B71910-E-T-P4S-UL
FAG B71911C.T.P4S.UL FAG B71911-C-T-P4S-UL
FAG B71911E.T.P4S.UL FAG B71911-E-T-P4S-UL
FAG B71912C.T.P4S.UL FAG B71912-C-T-P4S-UL
FAG B71912E.T.P4S.UL FAG B71912-E-T-P4S-UL
FAG B71913C.T.P4S.UL FAG B71913-C-T-P4S-UL
FAG B71913E.T.P4S.UL FAG B71913-E-T-P4S-UL
FAG B71914C.T.P4S.UL FAG B71914-C-T-P4S-UL
FAG B71914E.T.P4S.UL FAG B71914-E-T-P4S-UL
FAG B71915C.T.P4S.UL FAG B71915-C-T-P4S-UL
FAG B71915E.T.P4S.UL FAG B71915-E-T-P4S-UL
FAG B71916C.T.P4S.UL FAG B71916-C-T-P4S-UL
FAG B71916E.T.P4S.UL FAG B71916-E-T-P4S-UL
FAG B71917C.T.P4S.UL FAG B71917-C-T-P4S-UL
FAG B71917E.T.P4S.UL FAG B71917-E-T-P4S-UL
FAG B71918C.T.P4S.UL FAG B71918-C-T-P4S-UL
FAG B71918E.T.P4S.UL FAG B71918-E-T-P4S-UL
FAG B71919C.T.P4S.UL FAG B71919-C-T-P4S-UL
FAG B71919E.T.P4S.UL FAG B71919-E-T-P4S-UL
FAG B71920C.T.P4S.UL FAG B71920-C-T-P4S-UL
FAG B71920E.T.P4S.UL FAG B71920-E-T-P4S-UL
FAG B71921C.T.P4S.UL FAG B71921-C-T-P4S-UL
FAG B71921E.T.P4S.UL FAG B71921-E-T-P4S-UL
FAG B71922C.T.P4S.UL FAG B71922-C-T-P4S-UL
FAG B71922E.T.P4S.UL FAG B71922-E-T-P4S-UL
FAG B71924C.T.P4S.UL FAG B71924-C-T-P4S-UL
FAG B71924E.T.P4S.UL FAG B71924-E-T-P4S-UL
FAG B71926C.T.P4S.UL FAG B71926-C-T-P4S-UL
FAG B71926E.T.P4S.UL FAG B71926-E-T-P4S-UL
FAG B71928C.T.P4S.UL FAG B71928-C-T-P4S-UL
FAG B71928E.T.P4S.UL FAG B71928-E-T-P4S-UL
FAG B71930C.T.P4S.UL FAG B71930-C-T-P4S-UL
FAG B71930E.T.P4S.UL FAG B71930-E-T-P4S-UL
FAG B71932C.T.P4S.UL FAG B71932-C-T-P4S-UL
FAG B71932E.T.P4S.UL FAG B71932-E-T-P4S-UL
FAG B71934C.T.P4S.UL FAG B71934-C-T-P4S-UL
FAG B71934E.T.P4S.UL FAG B71934-E-T-P4S-UL
FAG B71936C.T.P4S.UL FAG B71936-C-T-P4S-UL
FAG B71936E.T.P4S.UL FAG B71936-E-T-P4S-UL
FAG B71938C.T.P4S.UL FAG B71938-C-T-P4S-UL
FAG B71938E.T.P4S.UL FAG B71938-E-T-P4S-UL
FAG B71940C.T.P4S.UL FAG B71940-C-T-P4S-UL
FAG B71940E.T.P4S.UL FAG B71940-E-T-P4S-UL
FAG B71944C.T.P4S.UL FAG B71944-C-T-P4S-UL
FAG B71944E.T.P4S.UL FAG B71944-E-T-P4S-UL
FAG B71948C.T.P4S.UL FAG B71948-C-T-P4S-UL
FAG B71948E.T.P4S.UL FAG B71948-E-T-P4S-UL


FAGB71905C.T.P4S.UL轴承我司目前有部分库存，您可致电我司咨询销售人员关于轴承B71905C.T.P4S.UL的图纸、轴承B71905C.T.P4S.UL价格或同型号其他品牌替换等资料！我司与FAG厂家常年批量订购B71905C.T.P4S.UL，以保证B71905C.T.P4S.UL轴承质量正宗，价格最优。订购原装FAG B71905C.T.P4S.UL轴承请拨打：0532-83735255、13061287818
