FAG轴承B7005E.T.P4S.UL机床主轴轴承B7005-E-T-P4S-UL

FAG轴承B7005E.T.P4S.UL机床主轴轴承B7005-E-T-P4S-UL

  • 型号：
  • B7005-E-T-P4S-UL
  • 品牌：
  • FAG轴承
  • 系列：
  • 机床主轴轴承
  • 内径d：
  • 25 mm
  • 外径D：
  • 47 mm
  • 厚度B：
  • 12 mm
FAG轴承B7005E.T.P4S.UL机床主轴轴承B7005-E-T-P4S-UL参数
品牌 FAG 型号 主轴轴承 B7005-E-T-P4S-UL 加工定制 是
是否标准件 标准件 样品或现货 现货 是否进口 进口
类型 钢球 用途 滑动轴承 材质 碳钢
尺寸 主轴轴承 B7005-E-T-P4S-UL






B7005E.T.P4S.UL进口FAG主轴轴承B7005-E-T-P4S-UL


调节，成对或单元安装，接触角 α = 25°，限制公差

 IMG_2985

IMG_2986

IMG_2987



主轴轴承 B7005-E-T-P4S, 调节，成对或单元安装，接触角 α = 25°，限制公差
径向载荷单向轴向载荷无密封脂润滑油润滑
主轴轴承 B7005-E-T-P4S, 调节，成对或单元安装，接触角 α = 25°，限制公差
主轴轴承 B7005-E-T-P4S, 调节，成对或单元安装，接触角 α = 25°，限制公差


d 25 mm

D 47 mm

B 12 mm


a 14 mm

Da H12 42 mm

da h12 30 mm

r1 min 0,6 mm

ra max 0,6 mm

ra1 max 0,3 mm

rmin 0,6 mm


m 0,07 kg
  质量
Cr 13600 N
  基本额定动载荷，径向
C0r 6200 N
  基本额定静载荷，径向
nG Fett 30000 1/min
  脂润滑时的极限转速
nG Öl 45000 1/min
  最少油润滑时的极限转速
Cur 640 N
  疲劳极限载荷，径向



7205CTYNSUL/P4.7206CTYNSUL/P4.7207CTYNSUL/P4
