订货号 | 2MM9102WI-CR-DUL | 品牌 | FAFNIR | 型号 | 2MM9102WI-CR-DUL |
旧型号 | 2MM9102WI-CR-DUL | 内径 | 15(mm) | 外径 | 32(mm) |
厚度 | 9(mm) | 重量 | 0.1(kg) | 保持架及其材料 | 胶木 |
滚动体列数 | 双列 | 滚道类型 | 深沟滚道 | 使用特性 | 高温 |
轴承材质 | 高温轴承钢 | 密封防尘形式 | M | 滚动体类型 | 球 |
密封盖 | 无密封 | 滚动体 | 钢球 | 精度等级 | P4 |
组配方式 | DU | 主要下游平台 | 亚马逊 | 主要销售地区 | 南美 |
有可授权的自有品牌 | 否 | 是否跨境货源 | 是 | 货号 | 2MM9102WI-CR-DUL |
系列 | 2MM9102WI-CR-DUL | 样品或现货 | 现货 | 是否提供加工定制 | 是 |
用途 | 通用 |
Dimensions
d - Bore |
15 mm0.5906 in |
D - Outer Diameter |
32 mm1.2598 in |
Bearing Width |
9 mm0.3543 in |
Contact Angle |
15 º |
do - Ball Diameter |
4.762500 mm0.18750 in |
Basic Load Ratings
C0 - Static Radial Rating |
3600 N820 lbf |
Ce - Dynamic Radial Rating1 | 7300 N1630 lbf |
Specifications
Ball Type |
STEEL |
Cage Type |
CR - Phenolic Outer Land Riding Cage |
Bearing Weight |
0.03 Kg0.07 lb |
Design Units |
METRIC |
Abutment and Fillet Dimensions
R - Inner Ring "To Clear" Radius2 | 0.3 mm0.012 in |
r - Outer Ring "To Clear" Radius3 | 0.3 mm0.012 in |
da - Inner Ring Backing Diameter |
18.900 mm0.750 in |
Da - Outer Ring Backing Diameter |
28.600 mm1.130 in |
