ELGES轴承GE180-UK-2RS-B

ELGES轴承GE180-UK-2RS-B

  • 型号：
  • GE180-UK-2RS-B
  • 品牌：
  • ELGES轴承
  • 系列：
  • 关节轴承
  • 内径d：
  • 180 mm
  • 外径D：
  • 260 mm
  • 厚度B：
  • 105 mm
ELGES轴承GE180-UK-2RS-B参数
品牌 ELGES 型号 关节轴承GE180-UK-2RS-B 加工定制 是
是否标准件 标准件 样品或现货 现货 是否进口 进口
类型 钢球 用途 关节轴承 材质 碳钢
尺寸 关节轴承GE180-UK-2RS-B








ELGES关节轴承GE180-UK-2RS-B


根据 DIN ISO 12 240-1 标准，免维护，两侧唇密封

 ELGES关节轴承GE180-UK-2RS-B

ELGES关节轴承GE180-UK-2RS-B (2)

ELGES关节轴承GE180-UK-2RS-B (3)



关节轴承 GE180-UK-2RS, 根据 DIN ISO 12 240-1 标准，免维护，两侧唇密封
径向载荷单向轴向载荷双向轴向载荷静转角误差和不对中动转角误差和不对中双侧密封终生润滑，免维护
关节轴承 GE180-UK-2RS, 根据 DIN ISO 12 240-1 标准，免维护，两侧唇密封


d 180 mm
  公差: 0 / -0,025
D 260 mm
  公差: 0 / -0,035
B 105 mm
  公差: 0 / -0,25

  0 - 0,1 mm
  径向内部游隙
C 80 mm
  公差: 0 / -0,7
Da min 219 mm

da max 198,9 mm

dK 225 mm

r1s min 1,1 mm
  倒角尺寸
r2s min 1,1 mm
  倒角尺寸
α 6 °


m 17,4 kg
  质量
Cr 4320000 N
  基本额定动载荷，径向
C0r 7200000 N
  基本额定静载荷，径向

 ELGES GE10-AX ELGES GE12-AX ELGES GE15-AX ELGES GE17-AX ELGES GE20-AX ELGES GE25-AX ELGES GE30-AX ELGES GE35-AX ELGES GE40-AX ELGES GE45-AX ELGES GE50-AX ELGES GE60-AX ELGES GE70-AX ELGES GE80-AX ELGES GE90-AX ELGES GE100-AX ELGES GE120-AX ELGES GE140-AX ELGES GE160-AX ELGES GE180-AX ELGES GE200-AX ELGES GE10-AW ELGES GE12-AW ELGES GE15-AW ELGES GE17-AW ELGES GE20-AW ELGES GE25-AW ELGES GE30-AW ELGES GE35-AW ELGES GE40-AW ELGES GE45-AW ELGES GE50-AW ELGES GE60-AW ELGES GE70-AW ELGES GE80-AW ELGES GE90-AW ELGES GE100-AW ELGES GE120-AW ELGES GE140-AW ELGES GE160-AW ELGES GE180-AW ELGES GE200-AW ELGES GE220-AW ELGES GE240-AW ELGES GE260-AW ELGES GE280-AW ELGES GE300-AW ELGES GE320-AW ELGES GE340-AW ELGES GE360-AW ELGES GE25-SX ELGES GE28-SX ELGES GE30-SX ELGES GE35-SX ELGES GE40-SX ELGES GE45-SX ELGES GE50-SX ELGES GE55-SX ELGES GE60-SX ELGES GE65-SX ELGES GE70-SX ELGES GE80-SX ELGES GE90-SX ELGES GE100-SX ELGES GE110-SX ELGES GE120SX ELGES GE130-SX ELGES GE140-SX ELGES GE150-SX ELGES GE160-SX ELGES GE170-SX ELGES GE180-SX ELGES GE190-SX ELGES GE200-SX ELGES GE25-SW ELGES GE28-SW ELGES GE30-SW ELGES GE35-SW ELGES GE40-SW ELGES GE45-SW ELGES GE50-SW ELGES GE55-SW ELGES GE60-SW ELGES GE65-SW ELGES GE70-SW ELGES GE80-SW ELGES GE90-SW ELGES GE100-SW ELGES GE110-SW ELGES GE120-SW ELGES GE130-SW ELGES GE140-SW ELGES GE150-SW ELGES GE160-SW ELGES GE170-SW ELGES GE180-SW ELGES GE190-SW ELGES GE200-SW ELGES ELGES GE6-FO ELGES GE8-FO ELGES GE10-FO ELGES GE12-FO ELGES GE15-FO-2RS ELGES GE17-FO-2RS ELGES GE20-FO-2RS ELGES GE25-FO-2RS ELGES GE30-FO-2RS ELGES GE35-FO-2RS ELGES GE40-FO-2RS ELGES GE45-FO-2RS ELGES GE50-FO-2RS ELGES GE60-FO-2RS ELGES GE70-FO-2RS ELGES GE80-FO-2RS ELGES GE90-FO-2RS ELGES GE100-FO-2RS ELGES GE110-FO-2RS ELGES GE120-FO-2RS ELGES GE140-FO-2RS ELGES GE160-FO-2RS ELGES GE180-FO-2RS ELGES GE200-FO-2RS ELGES GE220-FO-2RS ELGES GE240-FO-2RS ELGES GE260-FO-2RS ELGES GE280-FO-2RS ELGES ELGES GE6-FW ELGES GE8-FW ELGES GE10-FW ELGES GE12-FW ELGES GE15-FW-2RS ELGES GE17-FW-2RS ELGES GE20-FW-2RS ELGES GE25-FW ELGES GE30-FW-2RS ELGES GE35-FW-2RS ELGES GE40-FW-2RS ELGES GE45-FW-2RS ELGES GE50-FW-2RS ELGES GE60-FW-2RS ELGES GE70-FW-2RS ELGES GE80-FW-2RS ELGES GE90-FW-2RS ELGES GE100-FW-2RS ELGES GE110-FW-2RS ELGES GE120-FW-2RS ELGES GE140-FW-2RS ELGES GE160-FW-2RS ELGES GE180-FW-2RS ELGES GE200-FW-2RS ELGES GE220-FW-2RS ELGES GE240-FW-2RS ELGES GE260-FW-2RS ELGES GE280-FW-2RS ELGES ELGES GE20-HO-2RS ELGES GE25-HO-2RS ELGES GE30-HO-2RS ELGES GE35-HO-2RS ELGES GE40-HO-2RS ELGES GE45-HO-2RS ELGES GE50-HO-2RS ELGES GE60-HO-2RS ELGES GE70-HO-2RS ELGES GE80-HO-2RS ELGES GE12-LO ELGES GE16-LO ELGES GE20-LO ELGES GE25-LO ELGES GE32-LO ELGES GE40-LO ELGES GE50-LO ELGES GE63-LO ELGES GE70-LO ELGES GE80-LO ELGES GE90-LO ELGES GE100-LO ELGES GE110-LO ELGES GE125-LO ELGES GE160-LO ELGES GE200-LO ELGES GE250-LO ELGES GE320-LO ELGES GE6-DO ELGES GE8-DO ELGES GE10-DO ELGES GE12-DO ELGES GE15-DO ELGES GE17-DO ELGES GE20-DO ELGES GE25-DO ELGES GE30-DO-2RS ELGES GE35-DO-2RS ELGES GE40-DO-2RS ELGES GE45-DO-2RS ELGES GE50-DO-2RS ELGES GE60-DO-2RS ELGES GE70-DO-2RS ELGES GE80-DO-2RS ELGES GE90-DO-2RS ELGES GE100-DO-2RS ELGES GE110-DO-2RS ELGES GE120-DO-2RS ELGES GE140-DO-2RS ELGES GE160-DO-2RS ELGES GE180-DO-2RS ELGES GE200-DO-2RS-A ELGES GE220-DO-2RS-A ELGES GE240-DO-2RS-A ELGES GE260-DO-2RS-A ELGES GE6-UK ELGES GE8-UK ELGES GE10-UK ELGES GE12-UK ELGES GE15-UK ELGES GE17-UK-2RS ELGES GE20-UK-2RS ELGES GE25-UK-2RS ELGES GE30-UK-2RS ELGES GE35-UK-2RS ELGES GE40-UK-2RS ELGES GE45-UK-2RS ELGES GE50-UK-2RS ELGES GE60-UK-2RS ELGES GE70-UK-2RS ELGES GE80-UK-2RS ELGES GE90-UK-2RS ELGES GE100-UK-2RS ELGES GE110-UK-2RS ELGES GE120-UK-2RS ELGES GE140-UK-2RS-C ELGES GE160-UK-2RS-B ELGES GE180-UK-2RS-B ELGES GE200-UK-2RS-B ELGES GE220-UK-2RS-B ELGES GE240-UK-2RS-B ELGES GE260-UK-2RS-B ELGES GE280-UK-2RS-B ELGES GE300-UK-2RS-B ELGES GIR6-DO ELGES GIR8-DO ELGES GIR10-DO ELGES GIR12-DO ELGES GIR15-DO ELGES GIR17-DO ELGES GIR20-DO ELGES GIR25-DO ELGES GIR30-DO ELGES GIR35-DO-2RS ELGES GIR40-DO-2RS ELGES GIR45-DO-2RS ELGES GIR50-DO-2RS ELGES GIR60-DO-2RSELGES GIR70-DO-2RS ELGES GIR80-DO-2RS ELGES GIL6-DO ELGES GIL8-DO ELGES GIL10-DO ELGES GIL12-DO ELGES GIL15-DO ELGES GIL17-DO ELGES GIL20-DO ELGES GIL25-DO ELGES GIL30-DO ELGES GIL35-DO-2RS ELGES GIL40-DO-2RS ELGES GIL45-DO-2RS ELGES GIL50-DO-2RS ELGES GIL60-DO-2RS ELGES GIL70-DO-2RS ELGES GIL80-DO-2RS ELGES GAR6-DO ELGES GAR8-DO ELGES GAR10-DO ELGES GAR12-DO ELGES GAR15-DO ELGES GAR17-DO ELGES GAR20-DO ELGES GAR25-DO ELGES GAR30-DO ELGES GAR35-DO-2RS ELGES GAR40-DO-2RS ELGES GAR45-DO-2RS ELGES GAR50-DO-2RS ELGES GAR60-DO-2RS ELGES GAR70-DO-2RS ELGES GAR80-DO-2RS ELGES GAL6-DO ELGES GAL8-DO ELGES GAL10-DO ELGES GAL12-DO ELGES GAL15-DO ELGES GAL17-DO ELGES GAL20-DO ELGES GAL25-DO ELGES GAL30-DO ELGES GAL35-DO-2RS ELGES GAL40-DO-2RS ELGES GAL45-DO-2RS ELGES GAL50-DO-2RS ELGES GAL60-DO-2RS ELGES GAL70-DO-2RS ELGES GAL80-DO-2RS ELGES GIR6-UK ELGES GIR8-UK ELGES GIR10-UK ELGES GIR12-UK ELGES GIR15-UK ELGES GIR17-UK ELGES GIR20-UK ELGES GIR25-UK ELGES GIR30-UK ELGES GIR35-UK-2RS ELGES GIR40-UK-2RS ELGES GIR45-UK-2RS ELGES GIR50-UK-2RS ELGES GIR60-UK-2RS ELGES GIR70-UK-2RS ELGES GIR80-UK-2RS ELGES GIL6-UK ELGES GIL8-UK ELGES GIL10-UK ELGES GIL12-UK ELGES GIL15-UK ELGES GIL17-UK ELGES GIL20-UK ELGES GIL25-UK ELGES GIL30-UK ELGES GIL35-UK-2RS ELGES GIL40-UK-2RS ELGES GIL45-UK-2RS ELGES GIL50-UK-2RS ELGES GIL60-UK-2RS ELGES GIL70-UK-2RS ELGES GIL80-UK-2RS ELGES GAR6-UK ELGES GAR8-UK ELGES GAR10-UK ELGES GAR12-UK ELGES GAR15-UK ELGES GAR17-UK ELGES GAR20-UK ELGES GAR25-UK ELGES GAR30-UK ELGES GAR35-UK-2RS ELGES GAR40-UK-2RS ELGES GAR45-UK-2RS ELGES GAR50-UK-2RS ELGES GAR60-UK-2RS ELGES GAR70-UK-2RS ELGES GAR80-UK-2RS ELGES GAL6-UK ELGES GAL8-UK ELGES GAL10-UK ELGES GAL12-UK ELGES GAL15-UK ELGES GAL17-UK ELGES GAL20-UK ELGES GAL25-UK ELGES GAL30-UK ELGES GAL35-UK-2RS ELGES GAL40-UK-2RS ELGES GAL45-UK-2RS ELGES GAL50-UK-2RS ELGES GAL60-UK-2RS ELGES GAL70-UK-2RS ELGES GAL80-UK-2RS ELGES GIKR6-PB ELGES GIKR8-PB ELGES GIKR10-PB ELGES GIKR12-PB ELGES GIKR14-PB ELGES GIKR16-PB ELGES GIKR18-PB ELGES GIKR20-PB ELGES GIKR22-PB ELGES GIKR25-PB ELGES GIKR30-PB ELGES GIKL6-PB ELGES GIKL8-PB ELGES GIKL10-PB ELGES GIKL12-PB ELGES GIKL14-PB ELGES GIKL16-PB ELGES GIKL18-PB ELGES GIKL20-PB ELGES GIKL22-PB ELGES GIKL25-PB ELGES GIKL30-PB ELGES ELGES GAKR6-PB ELGES GAKR8-PB ELGES GAKR10-PB ELGES GAKR12-PB ELGES GAKR14-PB ELGES GAKR16-PB ELGES GAKR18-PB ELGES GAKR20-PB ELGES GAKR22-PB ELGES GAKR25-PB ELGES GAKR30-PB ELGES ELGES GAKL6-PB ELGES GAKL8-PB ELGES GAKL10-PB ELGES GAKL12-PB ELGES GAKL14-PB ELGES GAKL16-PB ELGES GAKL18-PB ELGES GAKL20-PB ELGES GAKL22-PB ELGES GAKL25-PB ELGES GAKL30-PB ELGES GIKR6-PW ELGES GIKR8-PW ELGES GIKR10-PW ELGES GIKR12-PW ELGES GIKR14-PW ELGES GIKR16-PW ELGES GIKR18-PW ELGES GIKR20-PW ELGES GIKR22-PW ELGES GIKR25-PW ELGES GIKR30-PW ELGES GIKL6-PW ELGES GIKL8-PW ELGES GIKL10-PW ELGES GIKL12-PW ELGES GIKL14-PW ELGES GIKL16-PW ELGES GIKL18-PW ELGES GIKL20-PW ELGES GIKL22-PW ELGES GIKL25-PW ELGES GIKL30-PW ELGES GAKR6-PW ELGES GAKR8-PW ELGES GAKR10-PW ELGES GAKR12-PW-A ELGES GAKR14-PW ELGES GAKR16-PW ELGES GAKR18-PW ELGES GAKR20-PW ELGES GAKR22-PW ELGES GAKR25-PW-A ELGES GAKR30-PW ELGES GAKL6-PW ELGES GAKL8-PW ELGES GAKL10-PW ELGES GAKL12-PW ELGES GAKL14-PW ELGES GAKL16-PW ELGES GAKL18-PW ELGES GAKL20-PW ELGES GAKL22-PW ELGES GAKL25-PW ELGES GAKL30-PW ELGES GK20-DO INA F-53272.02 NUKR F-12319 F-14973 F-16882.RLF


ELGES关节轴承GE180-UK-2RS-B轴承我司目前有部分库存，您可致电我司咨询销售人员关于轴承GE180-UK-2RS-B的图纸、轴承GE180-UK-2RS-B价格或同型号其他品牌替换等资料！我司与ELGES厂家常年批量订购GE180-UK-2RS-B关节轴承，以保证GE180-UK-2RS-B轴承质量正宗，价格最优。订购原装ELGES GE180-UK-2RS-B轴承请拨打：0532-83735255、13061287818
热销轴承型号：上一篇：INA油封G16X24X3 SKF NA6903轴承 NSK 7009ATYNSULP4轴承 KOYO 22VS2814E轴承 TIMKEN 5066/05185D/X1S-05066轴 KOYO 53234U轴承 NACHI 5202A轴承 TIMKEN T82轴承 NSK T7FC070轴承 KOYO NUP216轴承 下一篇：INA填塞片KA24-TN
ELGES轴承GE180-UK-2RS-B轴承图纸
