Item description
standard according to DIN 3771, ISO 3601-1, JIS 240 P+G, SMS 1586, BS 1806/AS 568 A, BS 4518
Materials:
NBR (70 Shore A) -N: Temperature range: -25°C to max. +100°C, FKM* (FKM, 80 Shore A) -V: Temperature range: -15°C to max. +200°C, EPDM (70 Shore A) -EP: Temperature range: -45°C to max. +130°C
Suitable:
NBR: Standard material for O-rings with a broad spectrum of use. Resistant to oils, lubricants and water (up to +80°C). Not resistant to fuels with high aromatic content and glycol based brake fluids
FKM: Resistant against high temperatures chemicals. Not resistant to hot water, water vapour, glycol based brake fluids and inorganic acids.
EPDM: Resistant to hot water, water vapour and chemicals. Specially designed for lees and diluted acids. Not resistant to mineral products and fuels.
Materials:
NBR (70 Shore A) -N: Temperature range: -25°C to max. +100°C, FKM* (FKM, 80 Shore A) -V: Temperature range: -15°C to max. +200°C, EPDM (70 Shore A) -EP: Temperature range: -45°C to max. +130°C
Suitable:
NBR: Standard material for O-rings with a broad spectrum of use. Resistant to oils, lubricants and water (up to +80°C). Not resistant to fuels with high aromatic content and glycol based brake fluids
FKM: Resistant against high temperatures chemicals. Not resistant to hot water, water vapour, glycol based brake fluids and inorganic acids.
EPDM: Resistant to hot water, water vapour and chemicals. Specially designed for lees and diluted acids. Not resistant to mineral products and fuels.
Properties
Internal Ø [mm] | 15,60 |
CordØ [mm] | 1,78 |
Material | FKM (80A)* |
Temperature range [°C] | -15 to +200 |
Further information on OR15,6X1,78V
Weight | 0,3 g / Pcs |
GTIN | 4050571107147 |
Customs duty number | 39269097 |
RoHS compliant | Yes |
