ASAHI带座轴承UCPA207

ASAHI带座轴承UCPA207

  • 型号：
  • UCPA207
  • 品牌：
  • ASAHI轴承
  • 系列：
  • 带座轴承
  • 内径d：
  • 35 mm
  • 外径D：
  • mm
  • 厚度B：
  • mm
ASAHI带座轴承UCPA207参数

 青岛辉瑞轴承有限公司供应旭精工ASAHI带座轴承UCPA207轴承座型号PA207轴承UC207青岛辉瑞轴承有限公司供应旭精工ASAHI带座轴承UCPA207轴承座型号PA207轴承UC207青岛辉瑞轴承有限公司供应旭精工ASAHI带座轴承UCPA207轴承座型号PA207轴承UC207青岛辉瑞轴承有限公司供应旭精工ASAHI带座轴承UCPA207轴承座型号PA207轴承UC207

ASAHI带座轴承UCPA207

ASAHI带座轴承UCPA207 (2)

ASAHI带座轴承UCPA207 (3)

ASAHI Unit NO.Dimensions mm in.Bolt Size mm inchBearing No.Housing No.Weight(kg)dhaebSglwBn


UCPA201 12 30.2 76 52 40 M10 15 11 62 31 12.7 M10 UC201 PA204 0.6
UCPA201-8 1/2 1-3/16 3 2-3/64 1-9/16 M10 19/32 7/16 2-7/16 1.22 0.5 M10 UC201-8 PA204 0.59
UCPA202 15 30.2 76 52 40 M10 15 11 62 31 12.7 M10 UC202 PA204 0.59
UCPA202-9 9/16 1-3/16 3 2-3/64 1-9/16 M10 19/32 7/16 2-7/16 1.22 0.5 M10 UC202-9 PA204 0.59
UCPA202-10 5/8 1-3/16 3 2-3/64 1-9/16 M10 19/32 7/16 2-7/16 1.22 0.5 M10 UC202-10 PA204 0.59
UCPA203 17 30.2 76 52 40 M10 15 11 62 31 12.7 M10 UC203 PA204 0.58
UCPA203-11 11/16 1-3/16 3 2-3/64 1-9/16 M10 19/32 7/16 2-7/16 1.22 0.5 M10 UC203-11 PA204 0.57
UCPA204 20 30.2 76 52 40 M10 15 11 62 31 12.7 M10 UC204 PA204 0.56
UCPA204-12 3/4 1-3/16 3 2-3/64 1-9/16 M10 19/32 7/16 2-7/16 1.22 0.5 M10 UC204-12 PA204 0.56
UCPA205 25 36.5 84 56 38 M10 15 12 72 34.1 14.3 M10 UC205 PA205 0.83
UCPA20S-13 13/16 1-7/16 3-5/16 2-13/64 1-1/2 M10 19/32 15/32 2-53/64 1.34 0.56 M10 UC205-13 PA205 0.87
UCPA205-14 7/8 1-7/16 3-5/16 2-13/64 1-1/2 M10 19/32 15/32 2-53/64 1.34 0.56 M10 UC205-14 PA205 0.86
UCPA205-15 15/16 1-7/16 3-5/16 2-13/64 1-1/2 M10 19/32 15/32 2-53/64 1.34 0.56 M10 UC205-15 PA205 0.84
UCPA205-16 1 1-7/16 3-5/16 2-13/64 1-1/2 M10 19/32 15/32 2-53/64 1.34 0.56 M10 UC205-16 PA205 0.83
UCPA206 30 42.9 94 66 50 M14 18 12 84 38.1 15.9 M14 UC206 PA206 1.12
UCPA206-17 1-1/16 1-11/16 3-45/64 2-19/32 1-31/32 M14 45/64 15/32 3-5/16 1.5 0.63 M14 UC206-17 PA206 1.15
UCPA206-18 1-1/8 1-11/16 3-45/64 2-19/32 1-31/32 M14 45/64 15/32 3-5/16 1.5 0.63 M14 UC206-18 PA206 1.14
UCPA206-19 1-3/16 1-11/16 3-45/64 2-19/32 1-31/32 M14 45/64 15/32 3-5/16 1.5 0.63 M14 UC206-19 PA206 1.12
UCPA206-20 1-1/4 1-11/16 3-45/64 2-19/32 1-31/32 M14 45/64 15/32 3-5/16 1.5 0.63 M14 UC206-20 PA206 1.11
UCPA207 35 47.6 110 80 55 M14 20 13 95 42.9 17.5 M14 UC207 PA207 1.48
UCPA207-20 1-1/4 1-7/8 4-21/64 3-5/32 2-11/64 M14 25/32 33/64 3-47/64 1.69 0.69 M14 UC207-20 PA207 1.54
UCPA207-21 1-5/16 1-7/8 4-21/64 3-5/32 2-11/64 M14 25/32 33/64 3-47/64 1.69 0.69 M14 UC207-21 PA207 1.51
UCPA207-22 1-3/8 1-7/8 4-21/64 3-5/32 2-11/64 M14 25/32 33/64 3-47/64 1.69 0.69 M14 UC207-22 PA207 1.48
UCPA207-23 1-7/16 1-7/8 4-21/64 3-5/32 2-11/64 M14 25/32 33/64 3-47/64 1.69 0.69 M14 UC207-23 PA207 1.45
UCPA208 40 49.2 116 84 58 M14 20 13 100 49.2 19 M14 UC208 PA208 1.89
UCPA208-24 1-1/2 1-15/16 4-9/16 3-5/16 2-9/32 M14 25/32 33/64 3-15/16 1.94 0.75 M14 UC208-24 PA208 1.93
UCPA208-25 1-9/16 1-15/16 4-9/16 3-5/16 2-9/32 M14 25/32 33/64 3-15/16 1.94 0.75 M14 UC208-25 PA208 1.9
UCPA209 45 54.2 120 90 60 M14 25 13 108 49.2 19 M14 UC209 PA209 1.98
UCPA209-26 1-5/8 2-9/64 4-23/32 3-35/64 2-23/64 M14 63/64 33/64 4-1/4 1 .9370 0.75 M14 UC209-26 PA209 2.08
UCPA209-27 1-11/16 2-9/64 4-23/32 3-35/64 2-23/64 M14 63/64 33/64 4-1/4 1 .9370 0.75 M14 UC209-27 PA209 2.04
UCPA209-28 1-3/4 2-9/64 4-23/32 3-35/64 2-23/64 M14 63/64 33/64 4-1/4 1 .9370 0.75 M14 UC209-28 PA209 2

ASAHI带座轴承UCPA207轴承我司目前有部分库存，您可致电我司咨询销售人员关于轴承UCPA207的图纸、轴承UCPA207价格或同型号其他品牌替换等资料！我司与ASAHI厂家常年批量订购UCPA207带座轴承，以保证UCPA207轴承质量正宗，价格最优。订购原装ASAHI UCPA207轴承请拨打：0532-83735255、13061287818
热销轴承型号：上一篇：ASAHI带座轴承UCFC212-36 进口SKF圆柱滚子轴承NU2208ECP NSK带座轴承UCFL204D1 菱形座FL2 TIMKEN HE2324轴承 IKO BA107Z轴承 TIMKEN 65385/65320轴承 NSK 120BAR10S轴承 KOYO 6219-2RU轴承 TIMKEN T9030FS-T9030S轴承 FAG AH39/900G-H轴承 下一篇：ASAHI带座轴承UCT205
ASAHI带座轴承UCPA207轴承图纸
