Main Dimensions & Performance DataDownload data sheet
d
12 mm
Bore diameter
D
26 mm
Outside diameter
T
9 mm
Height
rmin
0.3 mm
Minimum chamfer dimension
Ca
10,300 N
Basic dynamic load rating, axial
C0a
15,400 N
Basic static load rating, axial
Cua
710 N
Fatigue load limit, axial
nG
13,100 1/min
Limiting speed
nϑr
16,900 1/min
Reference speed
21 g
Weight
Dimensions
D1
13 mm
Bore diameter housing washer
d1
26 mm
Lip diameter shaft washer
Mounting dimensions
Da max
18 mm
Maximum diameter of housing shoulder
ra max
0.3 mm
Maximum recess radius
da min
20 mm
Minimum diameter shaft shoulder
Calculation factors
A
0.001
Minimum load factor
Temperature range
Tmin
-30 °C
Operating temperature min.
Tmax
150 °C
Operat
