Main Dimensions & Performance DataDownload data sheet
d
30 mm
Bore diameter
D
47 mm
Outside diameter
T
11 mm
Height
rmin
0.6 mm
Minimum chamfer dimension
Ca
18,800 N
Basic dynamic load rating, axial
C0a
40,000 N
Basic static load rating, axial
Cua
1,820 N
Fatigue load limit, axial
nG
9,300 1/min
Limiting speed
nϑr
8,100 1/min
Reference speed
0.066 kg
Weight
Dimensions
D1
32 mm
Bore diameter housing washer
d1
47 mm
Lip diameter shaft washer
Mounting dimensions
Da max
37 mm
Maximum diameter of housing shoulder
ra max
0.6 mm
Maximum recess radius
da min
40 mm
Minimum diameter shaft shoulder
Calculation factors
A
0.008
Minimum load factor
Temperature range
Tmin
-30 °C
Operating temperature min.
Tmax
150 °C
Operat
