ASAHI 外球面轴承 UC207 35mm X 72mm X 42.9mm_ASAHI轴承UC207

ASAHI 外球面轴承 UC207 35mm X 72mm X 42.9mm

青岛进口轴承 > 轴承型号 >

ASAHI 外球面轴承 UC207 35mm X 72mm X 42.9mm

型号：
UC207
品牌：
ASAHI轴承
系列：
内径d：
35mm mm
外径D：
72mm mm
厚度B：
42.9mm mm

ASAHI 外球面轴承 UC207 35mm X 72mm X 42.9mm参数

参数信息

品牌

ASAHI

型号

UC207

产地

日本

厚度

42.9mm

颜色分类

浅灰色

滚动体列数

单列

滚动轴承座材质：

铸铁

内径

图文详情

UCP207-20 has a combination of a cast iron pillow block housing with an anti-rotation device with self-alignment and a set screw locking chrome steel insert bearing with a slinger seal design. This specific unit is a standard duty pillow block bearing with a wide inner ring and two set screws and a cast iron unit with the standard base to center height with a grease fitting.
UCP200 Series Pillow Block Bearing is equipped with two specifically designed set screws that are positioned in the inner ring of the ball bearing to lock and attach to the shaft.

Common usage for UCP200 Series Pillow Block Bearing include: Agriculture, Automotive, Construction, Pump, Manufacturing Equipment, Sporting and Consumer Goods, Conveyor and Fan Assemblies, Farm Machinery, HVAC, Feed Mill, Economical housed bearing solution and many other Industrial Equipment.

UCP 207-20 Dimensions

Unit

Shaft Dia

Bolt Size

inch

1 1/4

1 7/8

6 9/16

1 7/8

25/32

43/64

45/64

3 21/32

1.6890

0.6890

M14

47.6

167

127

47.6

92.9

42.9

17.5

1/2

Interchange List

	Pre-Lube
PEER	UCP207-20
BROWNING	VPS-220
AMI/ASAHI	UCP207-20
NTN	UCP207-104D1
IPTCI	UCP207-20
SEAL MASTER	NP-20
DODGE PART #	123810
DODGE DESCRIPTION	P2B-SC-104
LINK-BELT	P3-U220N
FARNIR	YAS-1 1/4
SKF	SY 1-1/4 TF

Bearing Unit NO.	Shaft Dia d		Dimensions(mm)																	Bearing No.	Housing No.	Weight(kg)
	(in)	(mm)	o	g	p	q	s	b	k	e	a	w	j	l	h	t	z	Bi	n
UCT201-8 UCT202-9 UCT202-10 UCT203-11 UCT204-12 UCT201 UCT202 UCT203 UCT204	1/2 9/16 5/8 11/16	12 15 17 20	16	10	51	32	19	51	12	76	89	94	32	21	61	2	51	31	12.7	UC201-8 UC202-9 UC202-10 UC203-11 UC204-12 UC201 UC202 UC203 UC204	T204	0.56


UCT205-13 UCT205-14 UCT205-15 UCT205-16 UCT205	13/16 7/8 15/16 1	25	16	10	51	32	19	51	12	76	89	97	32	24	62	2	57	34.1	14.3	UC205-13 UC205-14 UC205-15 UC205-16 UC205	T205	0.63
UCT206-17 UCT206-18 UCT206-19 UCT206-20 UCT206	1-1/16 1-1/8 1-3/16 1-1/4	30	16	10	56	37	22	57	12	89	102	113	37	28	70	2	62	38.1	15.9	UC206-17 UC206-18 UC206-19 UC206-20 UC206	T206	0.95
UCT207-20 UCT207-21 UCT207-22 UCT207-23 UCT207	1-1/4 1-5/16 1-3/8 1-7/16	35	16	13	64	37	22	64	12	89	102	129	37	30	78	3	72	42.9	17.5	UC207-20 UC207-21 UC207-22 UC207-23 UC207	T207	1.09
UCT208-24 UCT208-25 UCT208	1-1/2 1-9/16	40	19	16	83	49	29	83	16	102	114	144	49	33	88	3	82	49.2	19	UC208-24 UC208-25 UC208	T208	1.72
UCT209-26 UCT209-27 UCT209-28 UCT209	1-5/8 1-11/16 1-3/4	45	19	16	83	49	29	83	16	102	117	144	49	35	87	3	82	49.2	19	UC209-26 UC209-27 UC209-28 UC209	T209	1.75
UCT210-29 UCT210-30 UCT210-31 UCT210-32 UCT210	1-13/16 1-7/8 1-15/16 2	50	19	16	83	49	29	86	16	102	117	149	49	37	90	3	87	51.6	19	UC210-29 UC210-30 UC210-31 UC210-32 UC210	T210	1.75
UCT211-32 UCT211-33 UCT211-34 UCT211-35 UCT211	2 2-1/16 2-1/8 2-3/16	55	25	19	102	64	35	95	22	130	146	171	64	38	106	4	92	55.6	22.2	UC211-32 UC211-33 UC211-34 UC211-35 UC211	T211	2.8

ASAHIUC207轴承我司目前有部分库存，您可致电我司咨询销售人员关于轴承UC207的图纸、轴承UC207价格或同型号其他品牌替换等资料！我司与ASAHI厂家常年批量订购UC207，以保证UC207轴承质量正宗，价格最优。订购原装ASAHI UC207轴承请拨打：0532-83735255、13061287818
