| 品牌 | 青岛瑞精 | 型号 | 6205/MT | 旧型号 | CSK25 |
| 内径 | 25（mm） | 外径 | 52（mm） | 厚度 | 15（mm） |
| 重量 | 1（kg） | 保持架及其材料 | 尼龙 | 使用特性 | 高温 |
| 用途 | 通用 | 滚动体列数 | 单列 | 滚道类型 | 直线滚道 |
| 样品或现货 | 现货 | 轴承材质 | 高温轴承钢 | 滚动体类型 | 球 |
| 角度 | 15度 | 密封盖 | 无密封 | 滚动体 | 钢球 |
| 类型 | 深沟球轴承 | 是否提供加工定制 | 是 |
- 服务说明
- 本产品支持七天无理由退货
205单向轴承6205单项离合器轴承CSK25轴承
205单向轴承6205单项离合器轴承CSK25轴承尺寸|轴承规格参数|轴承报价
内径：25mm
外径：52mm
宽度：15mm
型号：205单向轴承6205单项离合器轴承CSK25
类型：205单向轴承6205单项离合器轴承CSK25
品牌：205单向轴承6205单项离合器轴承CSK25
备注：205单向轴承6205单项离合器轴承CSK25
CSK series one way bearings is a sprag type freewheel , integrated into 6200 series ball bearing(except sizes 8 and 40), Also named OW BB KK etc. It provides you an one way clutch, and eliminates the need for a ball bearing. It gives a high degree of freewheeling accuracy while utilizing a minimum of space. It is bearing supported, shipped grease lubricated and protected against dust larger than 0.3mm diameter. Torque transmission is ensured by a press fit assembly into a rigid outer housing with N6 tolerance, and onto a shaft with n6 tolerance. The initial bearing radial clearance is set at C5, and is reduced if using the press fit asspecified. Operating temperature range:-20°C to +100°C. Peaks up to +120°C are acceptable for short periods.
The CSK series freewheel include CSK CSK…P CSK..PP type. CSK…P has the same construction and outside dimensions as type CSK, but has a keyway on the inner race, The type of CSK…PP clutches have a keyway on both inner race and outer race.
The CSK series one way cluth bearings have be used widely in washing machine, grass cutter, printing machine, textile machinery and food machinery etc.
